Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 760 mm | |
|---|---|---|
| Extended table length (with leaf) | 1700 mm | |
| Tabletop thickness | 30 mm | |
| Apron height under tabletop | 120 mm | |
| Leg section size at top connection | 80 x 80 mm | |
| Leg section size at floor contact | 50 x 50 mm | |
| Knee clearance height under apron | 640 mm | |
| Extension leaf width | 400 mm | |
| Overhang from leg to table edge | 200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Seating capacity (closed configuration) | 4 people | |
|---|---|---|
| Seating capacity (extended configuration) | 6 people | |
| Distributed tabletop static load capacity | 150 kg | |
| Product net weight | 52 kg | |
| Finish abrasion resistance | 1000 rubbing cycles | |
| Recommended warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop construction | Solid light oak or equivalent hardwood with matte clear lacquer | |
|---|---|---|
| Table legs | Solid hardwood, tapered profile with smooth sanded finish | |
| Support apron | Solid hardwood rails, mortise and tenon joinery to legs | |
| Extension leaf panel | Matching solid hardwood panel with edge joinery | |
| Extension sliding hardware | Powder-coated steel guide rails under tabletop | |
| Surface finish | Water-based matte clear lacquer, 0.15mm dry film thickness | |
| Floor contact pads | Felt protective pads attached to leg bases | |
| Joinery connectors | Zinc-plated steel confirmation screws and wood dowels | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Extension mechanism | Center split top slides apart to reveal internal stored 400mm leaf | |
|---|---|---|
| Extension operation | Tool-free manual leaf deployment, leaf locks into position when extended | |
| Surface use | Smooth sealed surface supports dining serving, writing and display items | |
| Seating access | No crossbars between legs blocking seated leg position on all sides | |
| Floor protection | Felt pads prevent scratching hardwood and soft flooring surfaces when table is moved | |
| Assembly requirement | Knock-down assembly required, legs attach to pre-installed apron hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Seats 6for family meals and casual gatherings, fits open-plan living spaces | |
|---|---|---|
| Small apartment dining nook | Closed 1350mm round footprint fits compact spaces without sharp corners | |
| Scandinavian/Japandi style interiors | Light natural wood finish complements neutral, minimalist interior palettes | |
| Casual home workspace | Stable flat surface supports laptop use and remote work outside dedicated office spaces | |
| Holiday entertaining | Extended 1700mm oval configuration accommodates extra guests during meals | |
| Rental property furnishing | Durable solid wood construction withstands regular use in long-term rental units |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables, applicable to performance validation | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for table stability, applicable to tilt resistance verification | |
| EN 71-3:2019 | Migration of certain elements, applicable if used in households with children |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural inspection | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to finish durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural inspection; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to finish durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
