Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 800 × 760 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Undertable knee clearance height | 640 mm | |
| Leg diameter | 60 mm | |
| Tabletop corner radius | 50 mm | |
| Apron height from floor | 660 mm | |
| Leg inset from table corner | 40 mm | |
| Edge overhang past apron | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 34 kg | |
|---|---|---|
| Distributed static tabletop load | 150 kg | |
| Seating capacity | 4 people | |
| Vertical leg static load per leg | 80 kg | |
| Finish abrasion resistance | 1000 cycles | |
| Wood moisture content at delivery | 12% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | Solid FAS-grade oak planks | |
|---|---|---|
| Table legs | Solid turned oak, straight cylindrical profile | |
| Support apron | Solid oak framing, concealed under tabletop | |
| Surface finish | Clear matte UV-cured lacquer | |
| Hardware connectors | Zinc-plated steel cam locks and wood screws | |
| Foot pads | Non-slip PE plastic floor protectors | |
| Joint construction | Mortise and tenon reinforced with metal hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly requirement | Knock-down flat pack, home assembly required | |
|---|---|---|
| Surface maintenance | Wipe clean with dry or slightly damp soft cloth | |
| Weight distribution design | Four corner leg support eliminates central cross-brace obstruction | |
| Corner safety design | Rounded edges eliminate sharp impact points for household use | |
| Floor protection function | Plastic foot pads prevent scuffing on hard flooring and rugs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Domestic dining room use | Suits 4-person households for daily meals in apartment or small home spaces | |
|---|---|---|
| Open-plan kitchen dining nook | Compact footprint fits small eat-in kitchen layouts without excess space use | |
| Small apartment dining area | 1.4m width fits tight urban home spaces paired with matching spindle chairs | |
| Scandinavian/Japandi interior schemes | Light natural wood finish matches neutral, minimalist home decor styles | |
| Casual home workspace secondary surface | Stable flat surface supports light paperwork or laptop use when not dining |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 71-3:2019 | Safety of toys – Migration of certain elements, applicable for household surface safety compliance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and finish quality inspection | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and finish quality inspection; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
