Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 220 kg | |
| Recommended maximum user weight for seating position | 150 kg | |
| Design service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop surface | High-gloss white lacquered MDF panel | |
|---|---|---|
| Left base pedestal | Matte white melamine-faced particleboard | |
| Right support leg | Orange-brown walnut veneer MDF panel | |
| Edge banding | 2mm thick PVC edge trim | |
| Internal drawer slides | Cold-rolled steel full-extension slides | |
| Cable grommets | ABS plastic recessed wire ports | |
| Structural connecting hardware | Zinc-plated steel cam lock fittings | |
| Desk foot pads | Adjustable nylon leveling feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated cable management system | Recessed desktop grommets and under-desk cable tray | |
|---|---|---|
| Left pedestal drawer storage | 3 full-extension soft-close drawers | |
| Leveling adjustment | 15mm height adjustable foot pads | |
| L-shaped work surface configuration | Dual-zone work layout for main tasks and side reference materials | |
| Modesty panel privacy screen | Fixed solid front panel under main desktop | |
| Knock-down assembly design | Flat-pack shipping with on-site assembly | |
| Scratch-resistant desktop coating | High-gloss UV cured lacquer surface | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Serves as primary work station for senior management in corporate headquarters | |
|---|---|---|
| President/General Manager office | Projects professional corporate image for client meetings and daily management work | |
| High-end law/finance firm partner office | Fits formal professional environment with durable, premium finish | |
| Open plan executive workstation | Defines dedicated work zone in premium open office layouts | |
| Recommended matching chair | High-back ergonomic executive chair with 100mm gas lift |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable to office work desk general safety and dimensional requirements | |
|---|---|---|
| EN 527-2:2016 | Applicable to office desk mechanical strength and stability test methods | |
| EN 13722:2004 | Applicable to office furniture storage unit strength and durability requirements |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to wooden office desk general technical requirements for size and stability | |
|---|---|---|
| GB/T 3327-2020 | Applicable to office desk strength, durability and stability test methods | |
| GB 18584-2001 | Applicable to formaldehyde emission limits for wooden furniture interior materials | |
| GB/T 4897.3-2003 | Applicable to particleboard substrate mechanical performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to wooden office desk general technical requirements for size and stability; 2. GB/T 3327-2020: Applicable to office desk strength, durability and stability test methods; 3. GB 18584-2001: Applicable to formaldehyde emission limits for wooden furniture interior materials; 4. GB/T 4897.3-2003: Applicable to particleboard substrate mechanical performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
