Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1100 x 750 mm | |
|---|---|---|
| Worktop thickness | 78 mm | |
| Pedestal cabinet panel thickness | 28 mm | |
| Knee clearance width | 1200 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance depth | 600 mm | |
| Cable grommet diameter | 80 mm | |
| Modesty panel height | 450 mm | |
| PVC edge band thickness | 2 mm | |
| Plinth base height | 100 mm | |
| Drawer internal height | 280 mm | |
| Drawer internal depth | 500 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desk net weight | 120 kg | |
|---|---|---|
| Worktop maximum static load | 70 kg | |
| File drawer static load capacity | 45 kg | |
| Utility drawer slide cycle rating | 50000 cycles | |
| Cable tray maximum static load | 5 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user capacity | 1 person | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | High-density MDF core with high-gloss white polyurethane lacquer | |
|---|---|---|
| Accent inlay panels | High-gloss black lacquered MDF geometric recessed details | |
| Pedestal cabinet body | 28mm thick lacquered MDF panel construction | |
| Edge treatment | 2mm thick impact-resistant PVC edge banding | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Cable port fitting | ABS plastic cable grommet with brush insert | |
| Leveling feet | Nylon-tipped adjustable steel glides | |
| Under-desk cable tray | Powder-coated cold-rolled steel tray | |
| Rear modesty panel | 18mm thick lacquered MDF panel | |
| Base plinth trim | Matching high-gloss white lacquered MDF kick plate | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Left-side desk grommet routed to under-desk steel cable tray, 80mm port diameter | |
|---|---|---|
| Drawer operation | Dual pedestal drawers with full-extension ball-bearing slides, lockable lower file drawers | |
| Leveling adjustment | Hidden base glides adjust 10mm vertically to compensate for uneven floors | |
| Privacy modesty panel | Full-width front modesty panel blocks seated user leg visibility from office entry | |
| Work surface layout | Central primary work zone with dedicated laptop/monitor area, side document storage surfaces | |
| Storage configuration | Left pedestal utility drawers and right pedestal file storage, central open knee recess | |
| Surface performance | High-gloss lacquer surface resists common office stains and light scratches | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for CEO/senior management private offices, wide work surface for executive tasks | |
|---|---|---|
| Corporate management suite | Pairs with matching background storage bookshelf for complete executive office set | |
| High-end commercial workspace | Ideal for premium modern corporate offices requiring polished professional aesthetic | |
| Single-seat workstation use | Designed for one primary user with dedicated knee clearance and adjacent storage | |
| Formal meeting work setting | Supports small in-desk meetings with visitors positioned opposite the work surface |
EU Market Access Requirements* EN Standards
| EN 527-2:2019 | Office worktables safety and strength requirements, applicable for fixed executive desks | |
|---|---|---|
| EN 14073-2:2006 | Office storage furniture safety requirements, applicable for integrated pedestals | |
| EN 13722:2004 | Furniture surface test methods for lacquered finishes, applicable for gloss surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated desk pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desk panel construction quality | |
|---|---|---|
| GB/T 4897.3-2018 | Particleboard/MDF requirements for furniture use, applicable for substrate performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk panel construction quality; 2. GB/T 4897.3-2018: Particleboard/MDF requirements for furniture use, applicable for substrate performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
