| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 2200 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 200 kg | |
|---|---|---|
| High-gloss finish abrasion resistance rating | 2000 cycles | |
| Surface heat resistance temperature | 80 °C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | 25 mm high-density particleboard core, E1 grade, laminated with high-gloss acrylic finish | |
|---|---|---|
| Desktop edge banding | 2 mm ABS edge banding, color-matched to finish, hot-melt bonded to all exposed edges | |
| Side support panels | 36 mm MDF core, high-gloss UV-cured white paint finish, seamless edge treatment | |
| Internal support frame | 1.2 mm thick rectangular steel tube, powder-coated black, welded joint construction | |
| Desktop work surface insert | 25 mm high-density particleboard, high-gloss black acrylic finish, flush fit to white frame panels | |
| Support base floor contact pads | 5 mm thick non-slip EVA rubber pads, adhered to all support base bottom edges | |
| Surface finish coating | UV-cured high-gloss clear topcoat, 0.15 mm dry film thickness, scratch-resistant formulation | |
| Internal structural bracing | 1.0 mm thick galvanized steel connecting brackets, zinc-plated, screw-fastened to panel joints | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Freestanding cantilever support structure | No required wall fixing, supports full desktop span without obstructive central legs, provides 1600 mm wide open knee space | |
|---|---|---|
| Dual-zone work surface layout | Primary 1600 mm wide black work zone for executive task use, 1200 mm wide side white surface for visitor meetings and document sorting | |
| Scratch-resistant gloss surface | Non-porous UV-cured finish, resists liquid spills and office supply abrasion, wipes clean with standard office disinfectant | |
| Stable anti-wobble support | Wide integrated side support base distributes weight evenly, 185 kg total unit weight eliminates movement during typing or writing | |
| Equipment-compatible flat surface | Level 50 mm thick top supports up to 80 kg point load, accommodates multiple monitors, desktop phones and decorative items without sag | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | applies to panel material strength, dimensional tolerance and finish quality acceptance | |
|---|---|---|
| GB 18580-2017 Formaldehyde emission limits for wood-based panels | applies to E1 grade substrate emission compliance for indoor office use | |
| GB/T 4897.3-2015 Particleboard for furniture use | applies to desktop core material structural performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: applies to panel material strength, dimensional tolerance and finish quality acceptance; 2. GB 18580-2017 Formaldehyde emission limits for wood-based panels: applies to E1 grade substrate emission compliance for indoor office use; 3. GB/T 4897.3-2015 Particleboard for furniture use: applies to desktop core material structural performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
