Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main work surface thickness | 50 mm | |
| Side return cabinet top depth | 800 mm | |
| Knee clearance height under work surface | 680 mm | |
| Knee clearance width at seated position | 900 mm | |
| Left pedestal base height | 680 mm | |
| Right cantilever base footprint width | 1200 mm | |
| Dark glass accent panel thickness on return | 12 mm | |
| Edge banding thickness | 2 mm | |
| Modesty panel height | 450 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Integrated drawer slide dynamic load per drawer | 35 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Desk net weight | 195 kg | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work top core | 18 mm thick MDF substrate | |
|---|---|---|
| Main work top finish | High-gloss UV-cured white lacquer | |
| Side return accent panel | 12 mm dark tinted tempered glass | |
| Support base structure | High-density MDF with matching high-gloss white finish | |
| Modesty panel | Matte black laminated composite panel | |
| Internal drawer components | 15 mm MDF with white melamine interior lining | |
| Base trim accent | 2 mm matte black PVC edge banding | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Hinges (if fitted) | Cold-rolled steel soft-close concealed hinges | |
| Hardware fasteners | Zinc-plated steel assembly hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Concealed under-desk cable tray with 80 mm desk grommets | |
|---|---|---|
| Left return storage configuration | Lockable two-drawer pedestal integrated into left support base | |
| Cantilever support design | Single angular right-side base eliminates obstructive legs | |
| Work surface orientation | Asymmetric L-shape with left-side return | |
| Storage drawer access | Front-facing drawer access on return pedestal | |
| Glossy surface maintenance | Non-porous stain-resistant lacquer finish | |
| Assembly configuration | Flat-pack CKD assembly with reinforced hardware joints | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive offices | Suited for CEO/manager private workspaces with large footprint and premium finish | |
|---|---|---|
| Corporate headquarters settings | Matches modern high-end office interior design aesthetics for premium facilities | |
| High-end home offices | Suitable for luxury residential workspaces requiring large work area and storage | |
| Executive meeting work zones | Side return provides space for small impromptu meetings or document review | |
| Commercial office projects | Designed for spec-grade commercial furniture fit-outs for senior staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial office use | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and durability requirements, applicable for ergonomic clearance | |
| EN 13722:2004 | Furniture test methods for surface finish durability, applicable for abrasion and stain resistance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer and cabinet component performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and finish quality | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks, applicable for load capacity and dimensional tolerances | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and finish quality; 2. GB/T 3327-2017: Performance standards for office desks, applicable for load capacity and dimensional tolerances; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
