Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2800 x 2400 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Left cylindrical pedestal diameter | 450 mm | |
| Knee well width (central opening) | 1200 mm | |
| Knee clearance height under desktop | 680 mm | |
| Right storage return dimensions | 1400 x 600 x 650 mm | |
| Suspended oval modesty panel dimensions | 1200 x 400 mm | |
| Orange central desktop inlay dimensions | 1200 x 400 mm | |
| Tempered glass cabinet door thickness | 12 mm | |
| Cable grommet diameter | 80 mm | |
| Storage drawer internal depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 45 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Cabinet door hinge cycle durability | 80000 cycles | |
| Recommended user capacity | 1 person | |
| Product net weight | 185 kg | |
| Surface scratch resistance | 2000 cycles | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main desktop substrate | E1-grade high-density MDF | |
|---|---|---|
| Desktop finish | High-gloss UV-cured white lacquer | |
| Accent components (inlay, modesty panel) | High-gloss orange painted MDF | |
| Left support pedestal | High-gloss white lacquered engineered wood | |
| Right return cabinet glass door | 12mm clear tempered glass | |
| Storage cabinet body | White lacquered particleboard core | |
| Edge sealing | 2mm thick white PVC edge banding | |
| Hardware (hinges, slides, locks) | Cold-rolled steel with electroplated finish | |
| Cable management fittings | Brushed aluminum alloy grommets and tray | |
| Adjustable foot pads | Nylon with non-slip rubber base | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Lockable storage drawers | 3 lockable drawers on return cabinet, keyed alike | |
|---|---|---|
| Glass-front display cabinet | 1 enclosed glass cabinet section on return | |
| Cable management system | 2 desktop grommets + under-desk cable tray | |
| Suspended modesty panel | Fixed oval orange panel under central knee opening | |
| Leveling adjustment | Adjustable feet on pedestal and return base | |
| Work surface zoning | Central orange inlay defines primary monitor/keyboard zone | |
| Fixed return configuration | Right-side attached return forms L-shaped work layout | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Designed for CEO, senior manager, or director private workspaces | |
|---|---|---|
| Modern corporate headquarters | Fits contemporary open-plan leadership office design schemes | |
| High-end home office | Suitable for luxury residential home executive workspaces | |
| Design studio leadership office | Works for creative agency director offices | |
| Boutique professional services office | Fits law firm, finance, or consulting firm partner offices |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety requirements | |
| EN 13722:2004 | Furniture storage units strength and durability | |
| EN 12521:2015 | Furniture strength, durability and safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limits for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use | |
| GB/T 11981-2001 | PCV edge banding performance for furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18584-2001: Formaldehyde emission limits for wooden furniture; 3. GB/T 4897.3-2003: Particleboard specification for furniture use; 4. GB/T 11981-2001: PCV edge banding performance for furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
