Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Main worktop static load capacity | 150 kg | |
|---|---|---|
| Desk net weight | 280 kg | |
| Recommended user capacity | 1 person | |
| Integrated LED strip operational lifespan | 30000 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desk top and cabinet panels | E0-grade engineered wood with dark walnut wood veneer finish, matte coating | |
|---|---|---|
| Left cabinet doors | 5mm thick dark gray tempered glass, aluminum alloy frame | |
| Support base plinths | Powder-coated steel frame with matching wood veneer cladding | |
| Cabinet internal shelf boards | 25mm thick melamine-faced engineered wood, dark gray inner finish | |
| Hardware fittings | Brushed metal soft-close hinges and sliding door tracks | |
| Integrated lighting | 3000K warm white LED strip lights, aluminum channel mounting | |
| Modesty panel | 18mm thick wood veneer panel, matching desk finish, recessed LED strip | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Sliding glass door storage | Two sliding tempered glass doors enclose left hanging storage compartment, soft-close track | |
|---|---|---|
| Open tiered shelving | Three horizontal open shelf tiers with integrated LED accent lighting for display and storage | |
| Left return work surface | Extended fixed side work surface for additional workspace, document placement or visitor interaction | |
| Integrated cable management | Concealed cable routing channel behind desk modesty panel for monitor and device power cords | |
| Drawers and closed storage | Concealed pull-out storage drawers within desk base for office supplies and document storage | |
| Ambient lighting control | Hardwired LED light strips with dimmable operation for shelf and desk ambient illumination | |
| Levelling adjustment | Adjustable feet on base plinths to compensate for uneven floor surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 30sqm senior management offices for president, director or general manager use | |
|---|---|---|
| High-end reception meeting space | Works as principal workspace in client-facing executive meeting rooms for formal discussions | |
| Corporate headquarters office space | Suits Grade A office building fit-outs requiring coordinated, premium executive furniture sets | |
| Luxury home office | Applicable for large residential home offices requiring professional workspace and ample storage | |
| Recommended matching chair | Pairs with high-back leather executive office chairs with 550 mm seat height |
EU Market Access Requirements* EN Standards
| Office furniture strength and durability | EN 527:2002+A1:2019 | |
|---|---|---|
| Formaldehyde emission from panels | EN 13986:2004+A1:2015 E1 grade | |
| Furniture surface abrasion resistance | EN 15185:2011 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| Panel formaldehyde emission | GB 18580E0 grade | |
|---|---|---|
| Desk structural stability | GB/T 3324 | |
| Tempered glass safety | GB 15763.2 |
This product must meet the following technical requirements: 1. Panel formaldehyde emission: GB 18580E0 grade; 2. Desk structural stability: GB/T 3324; 3. Tempered glass safety: GB 15763.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
