Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1000 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Seated knee clearance height | 700 mm | |
| Knee clearance width between leg frames | 1800 mm | |
| Metal slat leg width | 600 mm | |
| Metal slat dimensions | 20 x 20 mm square tube | |
| Slat spacing on leg frame | 40 mm | |
| Desktop overhang past leg frames | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 150 kg | |
|---|---|---|
| Suggested net weight range | 120 kg | |
| Seating capacity | 6 people | |
| Warranty period | 3 years | |
| Surface abrasion resistance | 1000 cycles | |
| Surface abrasion resistance rating | 1000 cycles | |
| Frame lateral load resistance | 60 kg | |
| Finish cold liquid resistance duration | 24 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | Solid walnut timber with natural matte clear lacquer finish, visible continuous wood grain | |
|---|---|---|
| Support leg frame | Matte black powder-coated carbon steel square tube slats, welded box frame structure | |
| Desktop edge treatment | Hand-finished natural live edge profile on long sides, eased square edge on ends | |
| Frame connection hardware | Zinc-plated steel M8 carriage bolts with threaded inserts embedded in wood underside | |
| Underside support bracing | Cross-braced steel square tube spanning between left and right leg frames | |
| Floor contact pads | Non-marking TPE rubber glides fitted to base of each leg slat | |
| Lacquer finish coating | UV-cured matte clear lacquer, 3-coat application with sealer and topcoat | |
| Steel frame coating thickness | 60 um | |
| Hardware kit fasteners | Class 8.8 zinc-plated steel bolts and nuts, included with assembly instructions | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Surface use function | Flat continuous work surface supports desktop monitors, document storage, meeting materials and executive display items | |
|---|---|---|
| Leg frame stability | Dual side slat frames with cross bracing provide lateral stability without central obstructive supports, creates unobstructed knee space for all seated positions | |
| Cable management | Underside open design allows free routing of power and data cables from floor outlets to desktop equipment, no pre-installed cable trays | |
| Assembly structure | Knock-down design with 6 bolted connections between desktop and two leg units, no on-site welding required | |
| Surface maintenance | Matte lacquer finish can be cleaned with standard neutral wood surface cleaners, resists common office liquid spills when wiped promptly | |
| Positioning flexibility | No fixed floor mounting required, freestanding unit can be repositioned in open office, executive suite or meeting room layouts | |
| Work surface function | Flat continuous solid wood work surface supports desktop monitors, document storage, meeting materials, and executive work items with 150kg static load capacity | |
| Leg frame stability function | Dual side slat frames with cross bracing provide lateral stability for 60kg horizontal load without central obstructive supports, creates unobstructed knee space for all seated positions | |
| Cable management function | Open underside design allows free routing of power and data cables from floor outlets to desktop equipment; accepts 60mm diameter desk grommets and 10kg capacity adhesive cable trays fitted without drilling visible top surfaces | |
| Assembly function | Knock-down design with 8 bolted connections between desktop and two leg units, no on-site welding required; adjustable glides allow 10mm height adjustment for leveling | |
| Surface maintenance function | Matte UV-cured lacquer finish can be cleaned with standard neutral wood surface cleaners, resists common office liquid spills for 24 hours when wiped promptly | |
| Positioning flexibility function | Freestanding unit requires no fixed floor mounting, 120kg net weight prevents unintended movement during regular use; can be repositioned in executive suites, meeting rooms, or open office layouts |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 packages | |
|---|---|---|
| Packaged desktop carton dimensions | 2500 x 1100 x 100 mm | |
| Packaged leg frame carton dimensions | 700 x 1100 x 120 mm per carton | |
| Total packaged gross weight | 140 kg | |
| Total shipping volume (CBM) | 0.46 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 60 units | |
| 40ft HQ container loading quantity | 150 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for director or C-level executive offices, provides generous work surface for daily tasks, visitor seating and document organization, matches natural wood and black metal modern office aesthetic | |
|---|---|---|
| Small meeting room | Accommodates up to 6 meeting participants, open leg design provides equal leg room for all seats, ideal for team discussion and client meeting spaces | |
| Open plan collaborative zone | Can be used as a standing or seated shared worktable for creative teams, durable solid wood surface withstands frequent daily use and equipment placement | |
| Showroom and reception area | Can be configured as a high-end product display or consultation table, natural wood finish creates a warm, premium impression for visiting clients | |
| Boutique co-working space | Serves as a dedicated hot-desking or meeting point for premium co-working membership areas, durable construction meets high-frequency commercial use requirements | |
| Small internal meeting room | Accommodates up to 6 meeting participants, open leg design provides equal unobstructed leg room for all seats, ideal for 6person team discussions and internal client meetings | |
| Open plan collaborative work zone | Can be used as a shared seated worktable for creative teams, 50mm solid wood surface withstands frequent daily use, prototype placement, and collaborative material layout | |
| High-end reception consultation area | Can be configured as a premium consultation table for client-facing reception areas, natural wood finish creates a warm, professional first impression for visiting clients |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, applicable for validating work surface height, clearance and dimensional suitability for office work | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements, applicable for structural stability and load performance acceptance | |
| EN 13722:2004 | Furniture - Assessment of surface resistance to cold liquids, applicable for validating desktop finish resistance to common office spills | |
| EN 15372:2008+A1:2016 | Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable for commercial use structural durability validation |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional tolerance, finish quality and structural stability acceptance of this solid wood desk | |
|---|---|---|
| GB/T 3327-2017 | Office desks and tables, applicable for height, clearance, load capacity and safety requirement validation for commercial office use | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde and VOC emission acceptance | |
| GB/T 4893.8-2013 | Test of surface coatings of furniture - Part 8: Determination of abrasion resistance, applicable for validating desktop finish durability against daily wear |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional tolerance, finish quality and structural stability acceptance of this solid wood desk; 2. GB/T 3327-2017: Office desks and tables, applicable for height, clearance, load capacity and safety requirement validation for commercial office use; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde and VOC emission acceptance; 4. GB/T 4893.8-2013: Test of surface coatings of furniture - Part 8: Determination of abrasion resistance, applicable for validating desktop finish durability against daily wear; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
