Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height | 700 mm | |
| Knee clearance width | 1200 mm | |
| Knee clearance depth | 600 mm | |
| Support base span (width) | 1400 mm | |
| Support base leg wall thickness | 2 mm | |
| Front power grommet strip length | 400 mm | |
| Grommet cable opening diameter | 80 mm | |
| Floor clearance under base | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 100 kg | |
|---|---|---|
| Recommended maximum user weight for seated use | 150 kg | |
| Surface abrasion resistance (Taber test) | 300 cycles | |
| Structural fastener cycle life | 10000 cycles | |
| Stability lateral load resistance | 200 N | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25 mm MDF core with high-gloss white lacquer finish | |
|---|---|---|
| Desktop edge trim | Matching high-gloss lacquered beveled edging | |
| Support frame upper section | Polished chrome-plated steel tubing | |
| Support frame lower leg sections | Powder-coated white steel outer panels | |
| Connection hardware | Zinc-plated steel bolts and brackets | |
| Front port trim plate | ABS plastic trim with integrated AC/USB port housing | |
| Floor contact pads | Non-slip rubber leveling pads | |
| Underside cable management tray | 0.8 mm thick cold-rolled steel with black powder coat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment | Fixed static 750 mm work height, no lift mechanism | |
|---|---|---|
| Integrated power access | Front-edge strip with AC power and USB charging ports | |
| Cable management | Underside steel tray routes cables from desktop ports to floor | |
| Leveling adjustment | Threaded rubber foot pads adjust 5 mm to compensate for uneven floors | |
| Storage integration | No built-in drawers or pedestals, open under-desk space for mobile filing cabinets | |
| Surface maintenance | Non-porous high-gloss finish wipes clean with damp mild detergent cloth | |
| Assembly configuration | Knock-down bolted assembly between desktop and pre-built base frame | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Serves as primary work surface for senior managers, 1800 mm width fits monitor and document layout | |
|---|---|---|
| Open plan manager workstation | Fits in partitioned open office areas for team lead seating, minimalist base avoids visual clutter | |
| Small conference meeting room | Functions as a 2-person meeting table for quick discussions, smooth surface supports laptops and documents | |
| Home office workspace | Suitable for dedicated home executive offices, reflective finish brightens smaller work rooms | |
| Matching configuration recommendation | Pair with high-back executive chair and mobile 3-drawer filing pedestal for full office setup |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Applies to office desk mechanical safety and strength requirements | |
|---|---|---|
| EN 527-3:2003 | Applies to office desk stability and structural durability test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk products static, dynamic and cycle load testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office desk dimensional, strength and stability requirements | |
|---|---|---|
| GB 18584-2001 | Applies to formaldehyde emission limits for wood-based furniture substrates |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office desk dimensional, strength and stability requirements; 2. GB 18584-2001: Applies to formaldehyde emission limits for wood-based furniture substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
