Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 1800 x 1600 x 750 mm | |
|---|---|---|
| Side return worktop depth | 600 mm | |
| Knee clearance height under main desk | 650 mm | |
| Knee clearance width between pedestal and support | 700 mm | |
| Executive chair overall dimensions | 700 x 750 x 1150 mm | |
| Executive chair seat height | 450 mm | |
| Visitor chair overall dimensions | 600 x 620 x 850 mm | |
| Visitor chair seat height | 450 mm | |
| Fixed storage pedestal width | 600 mm | |
| Worktop thickness | 50 mm | |
| Visitor chair 4-star base diameter | 680 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desk total net weight | 135 kg | |
|---|---|---|
| Desk worktop static load capacity | 100 kg | |
| Recommended user capacity for desk | 1 person | |
| Surface abrasion resistance (high-gloss top) | 2000 cycles | |
| Drawer slide cycle durability | 50000 cycles | |
| Hinge open-close cycle durability | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Executive chair static weight capacity | 150 kg | |
| Visitor chair static weight capacity | 120 kg | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desk worktop and panels | E1 grade high-density fiberboard with white high-gloss polyurethane finish, thin black PVC edge trim | |
|---|---|---|
| Executive chair upholstery | Top-grain match PU leather in camel tan color, 1.2mm thickness, 50000 double-rub abrasion rating | |
| Executive chair cushion foam | 45mm thick high-resilience polyurethane foam, 40kg/m³ density, 45% rebound rate | |
| Executive chair back foam | 35mm thick high-resilience polyurethane foam, 35kg/m³ density, 40% rebound rate | |
| Visitor chair shells | Molded bent plywood shell with white hard-coated outer finish, camel tan PU leather upholstered seat and inner back | |
| Visitor chair frames and bases | Polished die-cast aluminum 4-star base, 2.5mm wall thickness, 50mm diameter chrome-plated steel height column, non-marking black rubber glides | |
| Desk storage hardware | Chrome-plated steel drawer slides, 3-section full extension design, zinc-alloy recessed handle | |
| Desk modesty panel | 18mm thick white high-gloss engineered wood panel, matching desk body finish, full width under main worktop | |
| Desk worktop and structural panels | E1 grade high-density fiberboard with white high-gloss polyurethane finish, 2mm black PVC edge banding sealed on all cut edges | |
| Desk support base and pedestal cabinet | 18mm thick E1 grade high-density fiberboard with matching white high-gloss finish, 1mm black PVC edge trim on hidden panel edges | |
| Executive chair mechanism components | Class 3 steel gas lift, 2.5mm thick steel tilt chassis, polished die-cast aluminum 5-star base, 50mm black nylon casters | |
| Visitor chair base components | Polished die-cast aluminum 4-star base, 2.5mm wall thickness, 50mm diameter chrome-plated steel fixed height column, non-marking black rubber glides |
Adjustment / rotation / tilt / mobility / storage features
| Desk drawer operation | Single lockable central drawer in fixed pedestal, full-extension slide travel of 450mm, integrated lock securing all pedestal storage | |
|---|---|---|
| Executive chair function | 360-degree swivel, 100mm seat height adjustment via Class 3 gas lift, 12-degree recline with single-position tilt lock, polished 5-star base with 50mm nylon casters | |
| Visitor chair function | 360-degree swivel rotation on fixed-height column, no tilt or height adjustment, stationary non-rolling design with floor glides | |
| Desk cable management | Integrated cable port in corner worktop junction, hidden cable channel routed behind modesty panel to floor outlet | |
| Worktop spill resistance | Non-porous high-gloss surface, sealed edge trim to prevent liquid ingress into board core | |
| Storage configuration | Enclosed fixed pedestal with 1 stationery drawer, 1 suspension file drawer, no open storage shelves on main desk body | |
| Pedestal storage operation | Central lockable drawer system in fixed left pedestal, 450mm full-extension drawer slide travel, 1 upper stationery drawer and 1 lower suspension file drawer secured by single key lock | |
| Executive chair adjustment functions | 360-degree swivel rotation, 100mm pneumatic seat height adjustment, 12-degree synchronized back recline with single-position tilt lock, 5 casters for rolling mobility across hard flooring | |
| Visitor chair operation | 360-degree swivel rotation on fixed-height column, no tilt or height adjustment, stationary non-rolling design with floor glides to prevent movement during meetings | |
| Surface performance | Non-porous high-gloss polyurethane surface, sealed edge trim to prevent liquid ingress into board core, wipe-clean surface resistant to common office beverage spills | |
| Executive chair tilt mechanism | Tilt tension adjustable via chassis knob under seat to match user weight, locking in upright position for formal work settings | |
| Worktop edge design | Soft-radius 2mm black edge trim with no sharp corners, reducing impact injury risk at seated positions |
Verified carton / gross weight / assembly / loading data
| Total package count | 4 packages | |
|---|---|---|
| Desk main panel carton dimensions | 1850 x 850 x 120 mm | |
| Pedestal and hardware carton dimensions | 650 x 650 x 720 mm | |
| Chair set carton dimensions | 850 x 700 x 650 mm | |
| Total shipment gross weight | 185 kg | |
| Total shipment volume | 0.68 CBM | |
| On-site assembly time | 90 minutes | |
| 20ft GP container loading quantity | 36 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for 20sqm individual management/executive offices, providing dedicated work surface, storage, and integrated visitor seating for small meetings | |
|---|---|---|
| Small meeting/consulting space | Usable for 12sqm client consultation rooms, with fixed visitor seating positioned across the desk for face-to-face discussions | |
| Modern open-plan management workstation | Suitable for open-plan office supervisor positions, with sealed high-gloss surface that is easy to clean and maintain in high-traffic areas | |
| Recommended matching configuration | Pairs with 2 visitor chairs as shown, 1 executive chair, and under-desk mobile CPU holder for full workstation setup | |
| Color scheme suitability | White and camel tan color palette suits light-toned, bright modern office interiors with tile or light wood flooring | |
| Client consultation room | Usable for 12sqm client meeting and consultation spaces, with fixed visitor chairs positioned directly across the work surface for face-to-face discussions | |
| Open-plan supervisor workstation | Suitable for open-plan office team supervisor positions, with non-porous high-gloss surface that resists stains and is easy to clean in high-traffic work areas | |
| Modern minimalist office fit-out | Recommended for offices with light tile or light wood flooring and neutral wall finishes, where the white and camel tan color palette creates a bright, professional aesthetic |
EU Market Access Requirements* EN Standards
| Office desk safety requirement | EN 527:2002+A1:2019 | |
|---|---|---|
| Office chair safety requirement | EN 1335:2018 | |
| Upholstered furniture fire requirement | EN 1021:2014 | |
| Office desk safety standard | EN 527:2002+A1:2019 | |
| Office work chair safety standard | EN 1335:2018 | |
| Upholstery ignitability standard | EN 1021:2014 |
US and Canada office-furniture standards
| Desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Lounge/visitor chair standard | ANSI/BIFMA X2020 | |
| Executive task chair standard | ANSI/BIFMA X2017 | |
| Lounge/visitor seating standard | ANSI/BIFMA X2020 | |
| Office task chair standard | ANSI/BIFMA X2017 |
Standards applicable to China-market projects
| Desk structural requirement | GB/T 3326 | |
|---|---|---|
| Desk panel formaldehyde requirement | GB 18580 | |
| Chair structural requirement | GB/T 3324 | |
| Chair upholstery fire requirement | GB 20286 | |
| Office desk structural standard | GB/T 3326 | |
| Wood panel formaldehyde emission | GB 18580 |
This product must meet the following technical requirements: 1. Desk structural requirement: GB/T 3326; 2. Desk panel formaldehyde requirement: GB 18580; 3. Chair structural requirement: GB/T 3324; 4. Chair upholstery fire requirement: GB 20286; 5. Office desk structural standard: GB/T 3326; 6. Wood panel formaldehyde emission: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
