Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 1000 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Knee clearance width under desktop | 1500 mm | |
| Knee clearance height under desktop | 700 mm | |
| Base floor contact length | 1200 mm | |
| Desktop overhang front edge | 50 mm | |
| Work surface usable depth | 950 mm | |
| Side panel base thickness | 36 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 120 kg | |
|---|---|---|
| Net product weight | 115 kg | |
| Recommended user weight capacity | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Stability overturning load (front edge) | 40 kg | |
| Warranty period | 3 years | |
| Drawer slide load rating (if fitted) | 25 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | MDF engineered wood panel | |
|---|---|---|
| Desktop finish | High-gloss white UV cured lacquer | |
| Cantilever base structure | Integral MDF panel assembly | |
| Base finish | Matching high-gloss white lacquer | |
| Edge banding | 1mm PVC edge trim, gloss white | |
| Floor contact pads | Non-slip PE protective glides | |
| Internal reinforcement | 18mm MDF internal bracing | |
| Internal fasteners | Zinc-plated steel connecting hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Freestanding installation | No wall mounting required | |
|---|---|---|
| Cable management access | Optional 80mm desk grommet position | |
| Surface use suitability | Accommodates 2x 27 inch monitors plus keyboard and desk accessories | |
| Seating clearance | Accommodates standard 5-star base executive office chairs | |
| Modesty coverage | Left side geometric base provides full front modesty panel | |
| Floor protection | Base contact points distribute weight evenly to prevent floor indentation | |
| Optional storage add-on | Fits matching 3-drawer mobile pedestal under open knee space | |
| Surface stain resistance | Resists common office liquid spills for 24 hours without permanent staining | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 2 | |
|---|---|---|
| Largest carton dimensions | 2100 x 1100 x 120 mm | |
| Second carton dimensions | 1300 x 900 x 250 mm | |
| Total shipping gross weight | 130 kg | |
| Total shipping volume | 0.57 CBM | |
| On-site assembly time | 45 minutes | |
| 40ft HQ container loading quantity | 105 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
| Executive private office | Suitable for director or manager private offices as primary workstation, premium gloss finish matches modern executive interior design | |
|---|---|---|
| Modern meeting room | Usable as a small conference table for 4 person meetings, 2000mm length provides adequate space for meeting materials | |
| High-end reception area | Appropriate for upscale office reception or manager greeting zones, geometric design creates a strong contemporary visual focal point | |
| Design studio workspace | Suited for creative studio leadership workspaces, clean white surface and sculptural base align with minimalist design aesthetics | |
| Matching chair recommendation | Pairs with high-back leather executive office chairs with chrome 5-star bases, matching the premium modern styling of the desk | |
| Corporate boardroom ancillary surface | Usable as a presentation side table in boardrooms, gloss finish complements premium meeting room interiors |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, applicable for verification of working height and clearance dimensions | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements, applicable for stability and load testing | |
| EN 13722:2004 | Furniture - Test methods for the assessment of surface resistance to cold liquids, applicable for lacquer finish performance verification |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional tolerance, edge finishing and structural stability verification | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable for substrate formaldehyde emission and physical performance verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, required for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional tolerance, edge finishing and structural stability verification; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable for substrate formaldehyde emission and physical performance verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, required for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
