Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions (main top) | 2420 x 1350 x 750 mm | |
|---|---|---|
| Matching rear hutch dimensions | 2400 x 400 x 2000 mm | |
| Knee clearance height under worktop | 640 mm | |
| Knee clearance width (central user bay) | 800 mm | |
| Knee clearance depth from front edge | 600 mm | |
| Worktop thickness | 25 mm | |
| Center drawer front dimensions | 1200 x 120 mm | |
| Drawer internal usable depth | 450 mm | |
| PVC edge banding thickness | 2 mm | |
| Curved cantilever leg wall thickness | 36 mm | |
| Right pedestal support dimensions | 800 x 700 x 650 mm | |
| Cable grommet diameter (if fitted) | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static uniform load capacity | 181 kg | |
|---|---|---|
| Center drawer maximum static load | 25 kg | |
| Drawer slide full-extension cycle rating | 50000 cycles | |
| Net desk weight (excluding hutch) | 115 kg | |
| Matching hutch static shelf load per level | 30 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Recommended maximum user weight for seating use | 136 kg | |
| Recommended number of users | 1 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E1 grade medium-density fiberboard | |
|---|---|---|
| Worktop surface finish | White matte melamine laminate | |
| Base and support finish | Light oak-tone melamine laminate | |
| Edge treatment | 2mm thick PVC edge banding with rounded profile | |
| Drawer hardware | Black powder-coated steel slot handles, full-extension ball-bearing slides | |
| Cantilever leg internal frame | 1.5mm thick steel reinforcement core | |
| Right pedestal structure | E1 grade particleboard with matching laminate finish | |
| Hutch shelving material | 18mm thick E1 grade engineered wood with matching two-tone laminate | |
| Foot pads | Adjustable nylon leveling feet under supports | |
| Joinery hardware | Zinc-plated steel cam lock and confirmat screw connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Center drawer storage | Full-extension single front drawer for office supplies and documents, 450mm extension | |
|---|---|---|
| Right pedestal support | Enclosed block support for worktop right side, optional internal file storage available | |
| Curved cantilever leg support | Single continuous curved left leg extending to floor, unobstructed left-side legroom | |
| Rear hutch storage | Matching open multi-compartment bookshelf for books, decor and display items | |
| Cable management | Concealed under-desk cable routing tray, optional 60mm desktop grommets | |
| Leveling adjustment | Adjustable feet on all support points to compensate for uneven carpeted or hard flooring | |
| Drawer operation | Soft-close mechanism to prevent slamming, 50000 cycle rated slides | |
| Surface maintenance | Stain-resistant melamine finish, cleanable with soft dry or damp cloth | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for CEO or senior manager private workspaces with formal professional aesthetic | |
|---|---|---|
| High-end corporate office space | Ideal for premium corporate headquarters offices requiring upscale two-tone design | |
| Home executive workspace | Usable in large dedicated home offices for professional remote work setups | |
| Paired high-back executive chair configuration | Designed to pair with premium leather high-back executive office chairs | |
| Formal meeting and client reception | Appropriate for in-office client meetings held at the executive desk | |
| Display and document storage | Matching hutch provides open storage for reference books, decor and framed items |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, safety and strength requirements | |
|---|---|---|
| EN 527-2:2002+A1:2003 | Office work tables - Part 2: Mechanical safety requirements and test methods | |
| EN 13722:2004 | Furniture - Strength and durability of storage units for office use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard for office shelving and drawer components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel office desks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wood furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables: strength and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel office desks; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wood furniture; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables: strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
