Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1800 x 760 mm | |
|---|---|---|
| Main worktop depth | 900 mm | |
| Side return storage width | 600 mm | |
| Seated knee clearance height | 650 mm | |
| Seated knee clearance width | 1200 mm | |
| Worktop panel thickness | 30 mm | |
| PVC edge band thickness | 3 mm | |
| Cylindrical support pedestal diameter | 450 mm | |
| Embedded cable grommet size | 300 x 100 mm | |
| Inlaid writing pad dimensions | 800 x 400 mm | |
| Side return cabinet height | 620 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 120 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge cycle rating | 100000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Adjustable glide leveling range | 15 mm | |
| Recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop substrate | High-density MDF with walnut wood grain veneer | |
|---|---|---|
| Support base and cabinet carcass | E0-grade particleboard with matte off-white thermally fused laminate | |
| Inlaid writing surface | Beige matte faux leather laminate | |
| Edge trim | 3mm thick PVC edge banding with rounded profile | |
| Tapered left support pedestal | Lacquered MDF with internal steel reinforcement frame | |
| Side cabinet ventilation grille | Laser-cut MDF slotted panel | |
| Storage hardware | Cold-rolled steel full-extension drawer slides and concealed hinges | |
| Leveling feet | Nylon-tipped galvanized steel adjustable glides | |
| Cable grommet | Brushed ABS plastic rectangular port cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Embedded cable management port | Flip-open rectangular grommet routes power/data cables from worktop to under-desk channels | |
|---|---|---|
| Integrated closed side storage return | Dual-compartment cabinet holds office files, CPUs and supplies behind flush rounded doors | |
| Inlaid writing work zone | Smooth contrasting matte pad provides dedicated non-slip writing area separate from tech placement | |
| Side panel ventilation grille | Horizontal slotted vents exhaust heat from equipment stored inside return cabinet | |
| Floor leveling glides | Adjustable nylon feet compensate for 15mm of uneven factory/office floor slope | |
| Rounded safety edge profile | Soft radius edges on all worktop and cabinet corners eliminate sharp contact points | |
| Under-desk cable routing channel | Concealed raceway runs between support pedestal and return cabinet to hide wiring | |
| Lockable storage option | Cabinet doors accommodate core-compatible locks for secure document storage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Provides dedicated work and storage space for senior management in corporate offices | |
|---|---|---|
| Home office workspace | Fits dedicated home office rooms for professionals requiring formal work surfaces | |
| Manager workstation | Serves as private work station for department heads in mid-size office layouts | |
| Small meeting interview space | Accommodates 2 guest chairs across worktop for short in-office meetings | |
| Premium co-working private office | Used in high-end co-working dedicated private suite rentals |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office worktables mechanical safety and dimension requirements, applicable to ergonomic clearances | |
| EN 13722:2004 | Furniture test methods for strength and durability of storage units, applicable to cabinet |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to return cabinet testing | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable to material emissions and lifecycle |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural integrity | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks and tables, applicable to worktop load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to substrate material acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to worktop durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural integrity; 2. GB/T 3327-2016: Performance test methods for office desks and tables, applicable to worktop load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to substrate material acceptance; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to worktop durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
