Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1000 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Left cantilever support base footprint | 800 x 600 mm | |
| Right side storage return width | 600 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1200 mm | |
| Desktop usable depth at user position | 800 mm | |
| Side storage open shelf internal height | 350 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load | 200 kg | |
|---|---|---|
| Drawer slide rated load | 35 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Cable tray rated load | 10 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 145 kg | |
| Recommended user capacity | 1 person | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1 grade MDF panel | |
|---|---|---|
| Desktop finish | High-gloss piano baking lacquer | |
| Left cantilever structure | 1.5 mm thick polished chrome steel | |
| Storage cabinet panels | 18 mm thick E1 grade particleboard | |
| Edge treatment | 2 mm thick black PVC edge banding | |
| Drawer hardware | Cold-rolled steel ball-bearing slides | |
| Door hinges | Zinc alloy soft-close hinges | |
| Cable grommets | ABS plastic | |
| Base foot pads | Non-slip rubber | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Left curved cantilever support | Floor-fixed curved support creates open knee space without front legs | |
|---|---|---|
| Right integrated storage unit | Combination of closed cabinet doors and open display shelves for office items | |
| Cable management | Desktop grommets route power and data cables to under-desk space | |
| Drawer operation | Soft-close full-extension drawers with silent glide for file and supply storage | |
| Work surface layout | Asymmetrical curved front edge provides ergonomic seated access across full desk width | |
| Surface maintenance | Stain-resistant high-gloss lacquer surface wipes clean with non-abrasive cloths | |
| Anti-tip stability | Wide weighted cantilever base prevents forward tipping under normal desk loads | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Sized for director, manager or CEO private office spaces as primary workstation | |
|---|---|---|
| Modern corporate workspace | Two-tone high-gloss design fits contemporary minimalist office interiors | |
| Manager meeting use | Wide work surface accommodates small in-desk meetings with 2visitors | |
| Paired furniture set | Designed to pair with high-back executive office chair and matching wall bookcase | |
| Commercial office fit-out | Durable commercial grade construction suitable for long-term daily office use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements | |
| EN 15372:2016 | Furniture - Durability, strength and stability requirements for non-domestic tables |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel and finish quality inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables - strength and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel and finish quality inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables - strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
