Automatic mm / inch conversion · Core engineering specifications
| TV console overall dimensions (extended) | 3600 x 400 x 400 mm | |
|---|---|---|
| Square coffee table overall dimensions | 1000 x 1000 x 480 mm | |
| Round nesting coffee table overall dimensions | 630 x 630 x 500 mm | |
| TV console drawer internal dimensions | 330 x 132 x 100 mm | |
| TV console base ground clearance | 200 mm | |
| TV console cable opening diameter | 60 mm | |
| Square coffee table drawer internal dimensions | 450 x 450 x 120 mm | |
| Round table base diameter | 600 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| TV console top static load capacity | 100 kg | |
|---|---|---|
| Console drawer slide rated cycle life | 50000 cycles | |
| Recommended maximum TV size compatibility | 100 inch | |
| Set total net weight reference | 145 kg | |
| Sintered stone surface heat resistance | 200 °C | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| TV console body construction | 18mm CARB P2 grade engineered MDF with matte dark gray lacquer finish | |
|---|---|---|
| TV console and square table tops | 12mm matte sintered stone with marble-effect gray veining | |
| Drawer hardware | Zinc alloy gold-tone bar pulls with soft-close undermount slides | |
| Square coffee table legs | Tapered solid wood legs with dark gray stain finish | |
| Round coffee table top | 10mm thick tempered black safety glass with high-gloss finish | |
| Round coffee table base | Powder-coated metal inner frame wrapped in woven grid-textured fabric | |
| Adjustable foot pads | Non-slip TPE plastic pads fitted to all furniture leg bases | |
| TV console back panel | 5mm thick engineered hardboard with pre-cut cable access openings | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Console extendable side deck | Manual pull-out right-side deck to extend surface length for display items | |
|---|---|---|
| Nesting table design | Smaller round table slides partially under square table to reduce floor space when not in use | |
| Soft-close drawer operation | All 5 drawers (3 on console, 2 on square table) close silently with damped motion | |
| Cable management access | Rear panel cutouts allow routing of TV and media device power/AV cables | |
| Ventilation design | Raised base clearance provides air flow for media devices stored inside drawers | |
| Rounded corner safety | All external top and body corners are radiused to reduce impact injury risk | |
| Reversible extension configuration | Console pull-out deck can be installed on left or right side to fit room layout | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room use | Positioned against a wall under wall-mounted flat-screen televisions up to 100 inches | |
|---|---|---|
| Space-saving open-plan layouts | Nesting tables and extendable console adapt to small or large living room floor plans | |
| Modern luxury interior schemes | Dark gray finish with gold accents and stone tops complements contemporary minimalist decor | |
| Multi-functional surface use | Table tops support decor items, table lamps, snacks, drinks, and media accessories | |
| Low-profile lounge configuration | Low 500 mm height aligns with standard sofa seat heights for comfortable viewing |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables, applicable to both coffee tables | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units - Safety and performance, applicable to TV console | |
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for round table top |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood cabinet and table components | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture | |
| GB/T 3325-2017 | Test methods for metal furniture hardware, applicable to drawer slides and pulls |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood cabinet and table components; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture; 3. GB/T 3325-2017: Test methods for metal furniture hardware, applicable to drawer slides and pulls; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
