PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2400 × 420 × 400 mm
Top panel thickness	25 mm
Carcass side panel thickness	18 mm
Back panel thickness	5 mm
Interior shelf thickness	18 mm
Base plinth height	80 mm
Cable opening diameter	60 mm
Storage compartment interior height	270 mm
Maximum supported TV screen size	85 in
Clearance under plinth base	20 mm
Carcass Panel Thickness	25 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Top surface static load capacity	50 kg
Unit net weight	52 kg
Drawer/door hinge cycle rating	80000 cycles
Drawer slide load rating	25 kg
Surface abrasion resistance	2000 cycles
Recommended maximum user assembly time	60 minutes
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Angle / Life	165°; 80000 cycles
Anti-tip Fixing Reference	Products above 1200 mm should use at least 2 wall fixing points

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Top and front panels	E1-grade MDF substrate with matte white polyurethane finish
Lower plinth base	Powder-coated matte black engineered wood support frame
Back panel	Hardboard fiberboard with pre-cut cable access ports
Interior shelves	Matching white laminated engineered wood adjustable shelves
Door/drawer hardware	Zinc alloy push-to-open latches with soft-close steel hinges
Drawer slides	Cold-rolled steel full-extension ball-bearing slides
Surface edge treatment	Laser-sealed PVC edge banding to prevent moisture ingress
Floor protection pads	3mm thick non-marking felt pads affixed to base bottom
Edge Band Thickness	2 mm
Primary Connector Specification	Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Storage access mechanism	Handleless push-to-open doors and drawers with soft-close return
Cable management system	Two rear cutouts with removable grommets for AV cord routing
Interior shelf adjustability	Two position adjustable shelves to accommodate tall AV components
Ventilation design	Rear panel ventilation slots to dissipate heat from active electronics
Placement configuration	Freestanding floor placement aligned flush against living room walls
Drawer storage function	Two full-width soft-close drawers for remote controls and media accessories
Door cabinet function	Two side enclosed cabinets for larger media devices and hidden storage
Cable / Vent Opening Reference	80 mm diameter; recommend 4rear cable/vent openings

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Shipping carton dimensions	2460 x 480 x 160 mm
Gross shipping weight	58 kg
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Primary residential use	Modern living room placed under wall-mounted flat-screen televisions
Space size suitability	Recommended for living rooms 20 sqm and larger
Style compatibility	Works with minimalist, contemporary and modern urban interior design schemes
Secondary use case	Open-concept loft apartments as a long low media and display surface
Commercial application	Office break rooms or waiting lounge media zones for public screen placement
Surface use	Flat top accommodates decorative objects, soundbars and small potted plants

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Formaldehyde emission class	EN 13986:2004 E1 class
Furniture safety stability standard	EN 14749:2016
Surface resistance to cold liquids	EN 12720:2013

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Formaldehyde emission standard	GB/T 18580E1 grade
Surface coating safety standard	GB 18581
Furniture structural durability standard	GB/T 3324

Standardized tender description text

This product must meet the following technical requirements:
1. Formaldehyde emission standard: GB/T 18580E1 grade;
2. Surface coating safety standard: GB 18581;
3. Furniture structural durability standard: GB/T 3324;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · TVC-WB2400-LP

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · TVC-WB2400-LP

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · TVC-WB2400-LPOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Contemporary Two-Tone Low Profile TV Media Console (model TVC-WB2400-LP, unbranded) is a freestanding public and residential media storage solution defined by its streamlined, minimalist silhouette. Its low, elongated form sits flush against walls, pairing matte white upper panels with a contrasting matte black plinth base for a polished two-tone contemporary aesthetic, with no exposed hardware for clean visual lines. The unit spans 2400 x 420 x 400 mm, with an 80 mm tall plinth base that elevates the main carcass subtly, finished with laser-sealed 2 mm PVC edge banding for a seamless, refined look across all visible surfaces.
Constructed for durable daily use, the console’s top and front panels use E1-grade MDF substrate coated in a matte white polyurethane finish, while the lower plinth is a powder-coated matte black engineered wood support frame. Structural panels include a 25 mm thick top, 18 mm thick carcass sides and adjustable interior shelves, a 5 mm hardboard fiberboard back panel, and 3 mm non-marking felt floor protection pads affixed to the base to prevent floor scuffing. Hardware includes zinc alloy push-to-open latches paired with soft-close steel hinges rated for 80000 open/close cycles, and cold-rolled steel full-extension ball-bearing drawer slides rated for 25 kg of load per drawer. The top surface supports a 50 kg static load, each shelf holds up to 30 kg of distributed weight, and the matte surface resists abrasion across 2000 cycles of regular contact.
Functional design supports organized media storage and device use: two rear 60 mm diameter cable cutouts with removable grommets enable tidy AV cord routing, while rear panel ventilation slots dissipate heat from active electronics to support component longevity. Two full-width soft-close drawers store remotes and small media accessories, two side enclosed cabinets hold larger devices, and two-position adjustable shelves offer 270 mm of interior compartment height clearance to fit tall AV equipment. The flat, stable top surface holds soundbars, decorative objects, and small potted plants alongside television displays.
This console is suited for residential living rooms 20 sqm and larger positioned under wall-mounted flat-screen televisions, open-concept loft apartments as a combined media and display surface, and commercial spaces including office break rooms and waiting lounge media zones for public screen placement. It pairs seamlessly with minimalist, contemporary, and modern urban interior schemes. Procurement teams should note the unit ships across multiple cartons with a total packaged gross weight of 100 kg; end user assembly requires a maximum of 60 minutes to complete, with a 52 kg net assembled weight requiring two-person positioning for safe installation.
