Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2000 × 700 × 450 mm | |
|---|---|---|
| TV stand individual drawer width | 480 mm | |
| Coffee table individual drawer width | 620 mm | |
| Top surface thickness | 12 mm | |
| Carcass panel thickness | 18 mm | |
| Leg height for both units | 120 mm | |
| Drawer internal storage height | 150 mm | |
| TV stand top usable depth | 380 mm | |
| Coffee table top usable depth | 680 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| TV stand top static load capacity | 70 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Surface scratch resistance rating | 3000 cycles | |
| Set total net weight | 85 kg | |
| Available color option count | 5 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top surface for both units | 12mm matte engineered rock slab | |
|---|---|---|
| Main carcass material | E1-grade medium-density fiberboard with cream matte paint | |
| Leg and trim material | Titanium gold-finished stainless steel | |
| Drawer pull hardware | Horizontal gold stainless steel bar pulls | |
| Drawer interior lining | Smooth white melamine finish | |
| Drawer slide hardware | Cold-rolled steel soft-close under-mount slides | |
| Back panel material | 3mm hardboard backing | |
| Protective foot pads | Non-slip PE floor protection pads | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| TV stand storage configuration | 4 equal closed front drawers for media accessory storage | |
|---|---|---|
| Coffee table storage configuration | 2 equal closed front drawers for remote and small item storage | |
| Drawer operation | Soft-close damped pull-out drawers with no slam closure | |
| Top surface function | Heat-resistant wipe-clean flat surface for TV, decor and serving use | |
| Floor clearance design | 120mm raised leg clearance for robot vacuum access under both units | |
| Assembly design | Knock-down flat-pack construction with pre-drilled hardware points | |
| Cable management | Pre-cut rear cable exit openings for TV and media device wiring | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary use space | Modern residential living rooms positioned below wall-mounted TVs | |
|---|---|---|
| Suitable room size | 20 to 40 sqm open plan or dedicated living areas | |
| Target user group | Homeowners seeking coordinated light luxury living room furniture with hidden storage | |
| Recommended TV size compatibility | 65 to 85 inch flat-screen televisions | |
| Supporting decor style | Contemporary, minimalist, cream-style and light luxury interior design schemes | |
| Placement surface recommendation | Low-pile living room rugs or polished hard tile/wood flooring |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic storage furniture, applicable to drawer and load testing | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety for domestic living room tables, applicable to coffee table performance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF carcass quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to E1 MDF material acceptance | |
| GB/T 4897.3-2003 | Particleboard/fiberboard performance requirements for furniture structural use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF carcass quality inspection; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to E1 MDF material acceptance; 3. GB/T 4897.3-2003: Particleboard/fiberboard performance requirements for furniture structural use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
