| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 420 x 465 mm | |
|---|---|---|
| Leg height | 150 mm | |
| Top thickness | 15 mm | |
| Single drawer front width | 600 mm | |
| Drawer internal depth | 270 mm | |
| Drawer internal height | 110 mm | |
| Side panel fluted section width | 100 mm | |
| Clearance under cabinet | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Maximum supported TV size | 85 in | |
| Unit net weight | 66 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 15mm sintered stone with polished marble-look grey finish | |
|---|---|---|
| Drawer fronts | Matte off-white painted MDF panels | |
| Side panels | Dark grey fluted/reeded MDF with matte finish | |
| Support legs | Dark grey tapered solid wood with painted finish | |
| Drawer handles | Brushed gold-finish zinc alloy horizontal pulls | |
| Drawer slides | Side-mounted 3-section soft-close steel slides | |
| Back panel | 3mm hardboard with pre-drilled cable openings | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Three equal-width soft-close drawers with full extension access | |
|---|---|---|
| Media storage | Three partitioned drawer bays for remote controls, media accessories and cables | |
| Surface placement | Level polished top supports TV, table lamps and decorative objects | |
| Cable management | Rear cutouts for power and AV cable routing | |
| Floor protection | Padded feet on each leg prevent scratching hard flooring | |
| Assembly requirement | Knockdown construction with leg and handle installation required | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Positioned under wall-mounted TVs for media storage and display | |
|---|---|---|
| Apartment and condo spaces | Compact depth fits narrow floor plans without blocking walkways | |
| Light luxury interior schemes | Two-tone finish with gold hardware coordinates with modern and contemporary decor | |
| Media accessory organization | Closed drawers hide clutter while keeping remotes and cables accessible | |
| Coordinated living room sets | Matches the design of the companion oval marble-top coffee table |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety requirements for domestic storage furniture | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety for domestic storage |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18584-2001: Limit of harmful substances in wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
