| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| TV console overall dimensions | 2400 x 400 x 450 mm | |
|---|---|---|
| Coffee table overall dimensions | 1400 x 740 x 450 mm | |
| Sintered stone top thickness | 12 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 16 mm | |
| Adjustable shelf depth in TV console glass cabinet | 360 mm | |
| Coffee table drawer internal dimensions | 600 x 320 x 120 mm | |
| TV console side cabinet door width | 400 mm | |
| Metal leg height | 120 mm | |
| Floor clearance under units | 100 mm | |
| Tinted glass door dimensions on TV console | 800 x 200 mm | |
| Corner radius on top edges | 20 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| TV stand top static load capacity | 80 kg | |
|---|---|---|
| Total set net weight | 95 kg | |
| Sintered stone surface heat resistance | 180 °C | |
| Sintered stone surface scratch resistance (Mohs) | 6 | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table top material | 12mm light grey veined sintered stone | |
|---|---|---|
| Cabinet carcass material | 18mm E0 grade engineered wood board | |
| Side and door panel finish | Fluted ribbed matte light taupe laminate | |
| Central door panels | Smoked tinted tempered glass | |
| Leg and hardware material | Champagne gold plated stainless steel | |
| Drawer slide hardware | Soft-close full extension zinc alloy slides | |
| Door hinge hardware | Soft-close concealed steel hinges | |
| Back panel material | 16mm MDF board with matte finish | |
| Floor protection pads | 5mm thick non-slip rubber pads | |
| Internal shelf material | 16mm engineered wood with matching finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| TV console storage configuration | 2 side fluted-door cabinets, central glass-door cabinet, 2 end drawers | |
|---|---|---|
| Coffee table storage configuration | 2 central drawers with smoked glass fronts, fluted side panels | |
| Drawer operation | Soft-close full extension slides with gold bar pulls | |
| Cabinet door operation | Soft-close hinged doors with 110° opening angle | |
| Internal shelf adjustability | 3-position height adjustable shelves in glass compartments | |
| Cable management | 50mm diameter rear cable cutouts in TV console | |
| Surface maintenance | Wipe-clean non-porous sintered stone top | |
| Ventilation features | Rear ventilation gaps for media equipment | |
| Assembly structure | Knock-down flat pack construction with included hardware | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Modern residential living rooms | |
|---|---|---|
| Suitable TV size range | 65 to 85 inch flat screen televisions | |
| Suitable seating configuration | 3-seater to L-shaped sectional sofas | |
| Recommended usage | Media equipment storage, decorative display, everyday living room storage | |
| Interior style compatibility | Contemporary, light luxury, minimalist modern interiors | |
| Commercial application | Apartment common areas, boutique lounge spaces, hotel suite living areas | |
| Placement requirement | Position against flat wall with 100mm rear clearance for cable routing |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
