Automatic mm / inch conversion · Core engineering specifications
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total set net weight | 95 kg | |
|---|---|---|
| TV console top static load capacity | 100 kg | |
| Floor clearance height | 120 mm | |
| Recommended TV size compatibility | 55 to 75 inch | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Surface abrasion resistance | 3000 revolutions | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table and console tops | 12mm polished sintered stone with white marble veining, scratch-resistant, heat-resistant | |
|---|---|---|
| Main body frame | 18mm thick E1 grade particleboard with matte black thermofoil laminate wrap | |
| Drawer fronts | 15mm thick MDF with high-gloss white UV lacquer finish, black recessed edge trim | |
| Side accent panels | 15mm thick MDF with matte grey powder-coated lacquer finish, geometric angled cut | |
| Support legs | 30mm thick powder-coated black carbon steel, angled splay profile | |
| Central shelf panel | 5mm thick clear tempered glass, fully framed in black laminate | |
| Drawer hardware | Cold-rolled steel full-extension soft-close drawer slides, concealed mounting | |
| Internal drawer boxes | 12mm thick melamine-laminated particleboard, smooth wipe-clean interior | |
| Back panels | 3mm thick hardboard with black matte finish, pre-drilled for cable pass-through | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Soft-close drawer operation | All 10 drawers feature full-extension slides, slow-retract mechanism, no slam closure | |
|---|---|---|
| Central open display storage | TV console glass-enclosed shelf holds media devices, small decor, with unobstructed front access | |
| Under-unit cable routing | Pre-cut cable pass-through holes in back panel for TV and media device cord management | |
| Heat-resistant table top | Sintered stone surface supports hot mugs, small appliances up to 180°C without surface damage | |
| Robot vacuum access | 120mm floor clearance allows standard robot vacuums to clean under units without moving furniture | |
| Matching modular design | Identical finish, leg style and geometric accent on both units for coordinated living room layout | |
| Easy-clean surfaces | Non-porous stone top and lacquered panels wipe clean with damp cloth, no special treatment required | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary use case | Contemporary residential living room, positioned in front of sofa for media storage and surface access | |
|---|---|---|
| Recommended room size | 15 to 30 sqm open-plan or closed living rooms | |
| Style compatibility | Matches modern, minimalist, light-luxury and Scandinavian interior design schemes | |
| Target user group | Urban homeowners and renters seeking coordinated, low-maintenance living room storage solutions | |
| Configuration option | Can be used as a standalone TV console without coffee table for smaller spaces | |
| Adjacent furniture recommendation | Pairs with fabric or leather sofas, marble side tables and light wood shelving units | |
| Placement clearance requirement | Minimum 300mm clearance in front of drawers for full drawer extension access |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
