Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 450 × 450 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| TV stand total weight | 68 kg | |
|---|---|---|
| Coffee table total weight | 42 kg | |
| End table total weight | 18 kg | |
| Table top static load capacity | 50 kg per square meter | |
| Recommended maximum TV size | 85 inch | |
| Seating capacity alignment | 4 seat sofa set | |
| Surface scratch resistance rating | 6 Mohs | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Table top surface | 12mm polished sintered stone with marble-look white and grey veining | |
|---|---|---|
| TV stand body frame | High-density MDF panel with matte off-white polyurethane lacquer finish | |
| Coffee and end table body frame | High-density MDF panel with matching matte off-white lacquer finish | |
| Support legs | Polished gold-tone zinc alloy cylindrical legs with flared upper mounting brackets | |
| Drawer slides | Full-extension soft-close cold-rolled steel drawer slides | |
| Edge banding | PVC edge banding matching body color, sealed to rounded corners | |
| Table top backing board | 15mm thick particle board substrate under sintered stone top | |
| Foot pads | Non-slip PE plastic adjustable foot pads on each leg bottom | |
| Drawer front panels | Lacquered MDF panel with recessed seamless handleless design | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| TV stand storage access | 4 equal-width handleless drawers with push-to-open soft-close mechanism | |
|---|---|---|
| Coffee table storage access | 2 concealed side-mounted drawers for storing coasters, remotes and small living room items | |
| End table storage access | 1 lower enclosed storage compartment with push-to-open access | |
| Level adjustment | Adjustable foot pads on each leg allow 10mm height adjustment to compensate for uneven floors | |
| Surface functionality | Non-porous sintered stone top resists liquid stains, heat from hot mugs and daily scratches | |
| Cable management | Rear open cable pass-through slot on TV stand to route TV and media device power cords | |
| Mobility | Fixed non-caster leg design for stable permanent placement in living room layouts | |
| Impact safety | 20mm rounded corners on all table tops reduce injury risk from accidental bumps | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| TV stand carton dimensions | 2480 x 530 x 530 mm | |
|---|---|---|
| Coffee table carton dimensions | 1480 x 880 x 530 mm | |
| End table carton dimensions | 680 x 680 x 630 mm | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room placement | Position TV stand against main feature wall, coffee table centered in front of sofa, end table beside sofa arm | |
|---|---|---|
| Contemporary interior matching | Suits modern light luxury, minimalist and glamorous interior design schemes | |
| Family home use case | Suitable for daily family leisure, TV viewing and hosting small gatherings | |
| Show home and apartment furnishing | Ideal for residential show home staging and luxury rental apartment furnishing | |
| Sofa pairing recommendation | Pairs with 4seater upholstered sofas with 450 mm seat height | |
| Flooring compatibility | Suitable for placement on low-pile carpet, polished tile, hardwood and luxury vinyl flooring |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture surface resistance | EN 12720:2009+A1:2013 | |
|---|---|---|
| Furniture structural strength | EN 14749:2016 | |
| Furniture edge safety | EN 12529:1998 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Hard furniture surface durability | GB/T 4897.3 | |
|---|---|---|
| Furniture structural safety | GB 28007 | |
| Furniture finish VOC limits | GB 18584 | |
| Metal coating adhesion | GB/T 1979 |
This product must meet the following technical requirements: 1. Hard furniture surface durability: GB/T 4897.3; 2. Furniture structural safety: GB 28007; 3. Furniture finish VOC limits: GB 18584; 4. Metal coating adhesion: GB/T 1979; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
