Automatic mm / inch conversion · Core engineering specifications
| TV console overall dimensions | 2400 x 400 x 500 mm | |
|---|---|---|
| TV console leg height | 150 mm | |
| TV console end drawer front width | 600 mm | |
| TV console central glass compartment width | 1200 mm | |
| TV console top panel thickness | 12 mm | |
| TV console carcass panel thickness | 16 mm | |
| Large nesting coffee table diameter | 900 mm | |
| Large nesting coffee table height | 350 mm | |
| Small nesting coffee table diameter | 600 mm | |
| Small nesting coffee table height | 450 mm | |
| Coffee table top thickness | 10 mm | |
| Glass door thickness | 8 mm | |
| Cable management opening diameter | 60 mm | |
| Internal media shelf depth | 350 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm |
Net weight / load capacity / users / durability
| TV console top static load capacity | 80 kg | |
|---|---|---|
| Drawer slide cycle rating | 10000 open/close cycles | |
| Glass door hinge cycle rating | 10000 open/close cycles | |
| Sintered stone surface scratch resistance | 6 Mohs | |
| Set total net weight | 95 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| TV console top surface | 12mm polished sintered stone, scratch and stain resistant | |
|---|---|---|
| TV console carcass | 16mm E0 grade engineered wood, low-VOC matte light taupe paint | |
| TV console side and end panels | Vertical fluted MDF with matching matte taupe paint finish | |
| TV console central doors | 8mm tinted tempered smoked glass, magnetic touch latches | |
| TV console support legs | 1.5mm thick matte dark gray powder-coated steel, tapered slender profile | |
| TV console internal lighting | 3000K warm white LED strip lights, recessed under shelf | |
| Large coffee table top | 10mm polished light sintered stone, rounded polished edge | |
| Large coffee table base | Cylindrical fluted engineered wood, matching taupe paint finish | |
| Small coffee table top | 10mm dark smoked tempered glass, polished rounded edge | |
| Small coffee table base | Cylindrical dark wood-grain engineered wood, gunmetal gray metal trim rings | |
| Hardware components | Zinc alloy soft-close drawer slides, concealed glass door hinges | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| TV console outer storage | Two full-width soft-close drawers with integrated recessed pulls, for media accessory storage | |
|---|---|---|
| TV console central storage | Two hinged tinted glass doors, enclosing a single open compartment with internal LED lighting | |
| TV console cable management | Rear 60mm diameter cable pass-through cutout, positioned behind central glass compartment | |
| Coffee table nesting function | Small table tucks fully under the large table’s overhang to save floor space when not in use | |
| Drawer operation | Push-to-open assisted soft-close action, no protruding external handles | |
| Glass door operation | Magnetic touch-latch opening, no external handles for clean front aesthetic | |
| Internal LED lighting | Warm white accent lighting illuminates displayed media items, hardwired with inline switch | |
| Surface protection | Non-marking felt floor glides fitted to all legs and base bottoms, prevents hard floor scratching | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Modern residential living rooms, positioned against a wall under wall-mounted TVs | |
|---|---|---|
| Recommended TV size compatibility | 65 to 85 inch flat screen TVs | |
| Secondary use case | Small apartment open-plan living areas, nesting tables save floor space when not in use | |
| Target user group | Homeowners seeking light luxury modern minimalist living room furniture | |
| Recommended layout | Console placed 300mm from wall for cable access, large coffee table 400mm from sofa front edge | |
| Style compatibility | Matches contemporary, light luxury, minimalist, and modern wabi-sabi interior schemes | |
| Commercial suitability | High-end apartment model homes, boutique hotel lounge areas, residential VIP waiting spaces |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard specifications, applicable to engineered wood structural panels | |
|---|---|---|
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for door and table tops | |
| EN 14749:2016 | Safety requirements for domestic storage furniture including TV stands | |
| EN 71-3:2019 | Migration of certain elements for surface coatings and paint finishes |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to carcass and panel components | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to engineered wood structural panels | |
| GB 15763.2-2005 | Safety glazing materials for building, applicable to tempered glass door and table top components | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 29498-2013 | General technical requirements for household and similar use electrical lighting for LED accent strips |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to carcass and panel components; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable to engineered wood structural panels; 3. GB 15763.2-2005: Safety glazing materials for building, applicable to tempered glass door and table top components; 4. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 5. GB/T 29498-2013: General technical requirements for household and similar use electrical lighting for LED accent strips; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
