Automatic mm / inch conversion · Core engineering specifications
| Overall console dimensions (fully extended) | 2400 x 450 x 400 mm | |
|---|---|---|
| Console leg height | 150 mm | |
| Left drawer front dimensions per unit | 550 x 180 mm | |
| Central open media bay internal dimensions | 450 x 350 x 150 mm | |
| Right elevated open compartment dimensions | 850 x 450 x 220 mm | |
| Larger nesting coffee table dimensions | 800 x 800 x 450 mm | |
| Smaller nesting storage coffee table dimensions | 600 x 600 x 400 mm | |
| Drawer internal usable depth | 380 mm | |
| Sintered stone top thickness | 12 mm | |
| Carcass panel thickness | 18 mm | |
| Open shelf clearance height | 150 mm | |
| Floor clearance under console | 150 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Console top uniform static load capacity | 100 kg | |
|---|---|---|
| Sintered stone surface water absorption rate | <0.05% | |
| Sintered stone surface scratch resistance rating | Level 6 Mohs | |
| Recommended maximum supported TV screen size | 85 inch | |
| Drawers soft-close slide cycle rating | 50000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Console main top surface | 12mm polished light grey sintered stone | |
|---|---|---|
| Console carcass frame | 18mm E1-grade engineered wood with dark matte baked paint finish | |
| Left drawer fronts | Engineered wood with champagne beige matte baked paint finish | |
| Support legs for console and coffee tables | 20x20mm powder-coated black carbon steel angled sled legs | |
| Drawer internal linings | Melamine-lined engineered wood with smooth anti-scratch finish | |
| Back panel of console | 5mm thick fiberboard with pre-cut cable routing openings | |
| Large coffee table top | 12mm polished light grey sintered stone matching console top | |
| Small coffee table top | Dark matte engineered wood with scratch-resistant melamine finish | |
| Small coffee table storage body | Champagne beige engineered wood matching console drawer finish | |
| Drawer hardware | Cold-rolled steel soft-close concealed drawer slides | |
| Open shelf surfaces | Matte dark engineered wood matching carcass finish | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Manual extendable console section | Sliding right segment adjusts total length from 1800mm to 2400mm for variable wall fit | |
|---|---|---|
| Soft-close drawer operation | Two left-side drawers feature damping slides that close silently without slamming | |
| Open media storage bays | Central and right open compartments allow unobstructed remote signal and ventilation for AV gear | |
| Integrated cable management | Pre-drilled openings at back of open bays route power and AV cables out of sight | |
| Nesting coffee table configuration | Smaller table slides fully under larger table to save floor space when not in use | |
| Small coffee table hidden storage | Round enclosed compartment under top stores remotes, coasters and small living room items | |
| Floor protection design | Plastic glides fitted to leg bases prevent scratching hard flooring surfaces | |
| Elevated right display shelf | Raised compartment provides dedicated space for decor, books or soundbar placement | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned against main wall below wall-mounted TV for media and display storage | |
|---|---|---|
| Small to medium apartment use | Extendable length and nesting tables adapt to variable wall and floor space constraints | |
| Modern light luxury interior schemes | Two-tone beige and dark finish, sintered stone top and black metal legs match contemporary Italian-minimal decor | |
| Open plan lounge areas | Low profile does not block sight lines while providing accessible storage for media and living items | |
| Matching set configuration | Paired nesting coffee tables create coordinated visual style without requiring separate furniture selection | |
| AV equipment setup | Open bays accommodate soundbars, set-top boxes, game consoles and routers with proper ventilation |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety requirements for domestic and kitchen storage units and worktops, applicable for cabinet stability testing | |
|---|---|---|
| EN 12520:2015 | Furniture strength, durability and safety requirements for domestic seating tables, applicable for coffee table testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet structural performance verification | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable for carcass board quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet structural performance verification; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification; 3. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable for carcass board quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
