Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 600 × 600 × 450 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 18 kg | |
|---|---|---|
| Tabletop static load capacity | 50 kg | |
| Recommended maximum seated users | 2 | |
| Drawer slide cycle rating | 10000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | Solid rubberwood with natural matte clear finish | |
|---|---|---|
| Supporting legs | Solid rubberwood with rounded edge profile | |
| Middle open shelf | Solid rubberwood panel, fixed between leg frames | |
| Lower storage drawer front | Solid rubberwood panel with integrated recessed pull handle | |
| Drawer box sides and base | 12mm thick plywood with wood veneer match | |
| Drawer slides | Cold-rolled steel side-mount 3/4 extension slides | |
| Surface finish | Water-based matte clear lacquer, 3 coat application | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lower drawer storage | Front-mounted single drawer with recessed pull, 100mm internal height for small item storage | |
|---|---|---|
| Open middle shelf storage | Fixed open flat shelf spanning full interior, for frequently accessed items like books and remotes | |
| Leveling adjustment | 4 hidden floor glides at leg bases, 5mm height adjustment for uneven floors | |
| Surface usage | Flat square top with rounded corners, supports drinkware, decor, and reading materials | |
| Assembly structure | Knock-down construction with cam-lock and bolt hardware for residential assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room use | Position in front of sofas for beverage, decor and reading material placement | |
|---|---|---|
| Apartment studio use | Suitable for small space living due to compact square footprint and dual-tier storage | |
| Casual lounge area use | Placed between accent chairs in reading nooks to hold drinks and books | |
| Home office side use | Used as an oversized side table next to lounge seating for documents and devices |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Surface durability recommendation | EN 15187:2006, furniture surface resistance to cold liquids | |
|---|---|---|
| Structural safety recommendation | EN 12521:2015, safety requirements for domestic tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB 18584≤0.124 mg/m³ for indoor wood furniture | |
|---|---|---|
| Structural stability recommendation | GB/T 10357.1table strength and stability test methods |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB 18584≤0.124 mg/m³ for indoor wood furniture; 2. Structural stability recommendation: GB/T 10357.1table strength and stability test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
