Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 660 × 457 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Leg diameter at floor contact | 35 mm | |
| Splayed leg outward angle | 12 degrees | |
| Under-table floor clearance | 427 mm | |
| Tabletop edge radius | 60 mm | |
| Leg spacing along long edge | 820 mm | |
| Leg spacing along short edge | 460 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop distributed static load | 23 kg | |
|---|---|---|
| Net product weight | 16 kg | |
| Leg joint vertical pull-out resistance | 50 kg | |
| Recommended maximum place setting count | 4 | |
| Surface impact resistance | 1.2 J | |
| Warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm thick E1 grade engineered wood particleboard | |
|---|---|---|
| Tabletop finish | Matte white UV-cured lacquer coating, 0.15mm dry film thickness | |
| Leg construction | Solid natural beech wood, clear matte natural finish | |
| Leg mounting hardware | Zinc-plated M8 hanger bolts with steel threaded inserts | |
| Underside support bracing | 20mm thick solid wood cross cleats at leg attachment points | |
| Edge treatment | Rounded profile matching tabletop material, fully lacquered to match surface | |
| Foot pads | 5mm thick non-slip PE floor protection pads at each leg base | |
| Moisture content of wood components | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structural configuration | Fixed non-folding, non-height-adjustable rigid frame | |
|---|---|---|
| Floor protection | PE foot pads prevent floor scratches and reduce sliding on hard surfaces | |
| Surface maintenance | Matte finish resists minor liquid stains and wipes clean with damp cloth | |
| Assembly method | Knock-down flat pack, legs attach to underside with included hex key | |
| Load distribution | Four splayed legs spread weight evenly for stable placement on low-pile rugs | |
| Edge safety | Rounded oval edges eliminate sharp corners for household use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary placement | Central position in front of 3seater fabric or leather sofas in residential living rooms | |
|---|---|---|
| Secondary application | Small apartment lounge or studio open seating areas with low-profile seating | |
| Commercial application | Casual lounge areas in boutique offices, co-working spaces or cafe waiting zones | |
| Floor compatibility | Suitable for placement on low-pile rugs, hardwood, laminate and tile flooring | |
| Recommended complementary pieces | Fabric lounge sofas, light wood side tables, neutral toned area rugs |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use, tables: safety, strength and durability requirements | |
|---|---|---|
| EN 13722:2004 | Furniture: assessment of surface resistance to cold liquids for coated furniture tops |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and dimensional tolerance checks | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wooden furniture, required for E1 grade substrate verification | |
| GB/T 4893.4-2013 | Surface film adhesion test for furniture finishes, applicable for lacquer coating durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and dimensional tolerance checks; 2. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wooden furniture, required for E1 grade substrate verification; 3. GB/T 4893.4-2013: Surface film adhesion test for furniture finishes, applicable for lacquer coating durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
