Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 914 x 914 x 750 mm | |
|---|---|---|
| tabletop thickness | 36 mm | |
| leg splay outer diameter at floor | 780 mm | |
| under-table knee clearance height | 680 mm | |
| cross brace height above floor | 420 mm | |
| leg cross-section at floor contact | 30 x 30 mm | |
| tabletop edge radius | 6 mm | |
| cross brace member cross-section | 25 x 40 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| net weight | 24 kg | |
|---|---|---|
| static tabletop load capacity | 114 kg | |
| seating capacity | 4 people | |
| frame lateral stability load | 45 kg | |
| surface static friction coefficient | 0.4 | |
| warranty period | 1 year | |
| available finish options | 4 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | Solid hardwood | |
|---|---|---|
| tabletop finish | Low-VOC matte walnut-toned lacquer | |
| support legs | Solid hardwood | |
| cross brace | Solid hardwood | |
| leg-to-top joinery | Metal hanger bolt reinforced wood-to-wood joint | |
| floor contact pads | Non-marking 3mm thick felt pads | |
| seam gap tolerance | 0.5 mm | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| assembly requirement | Knock-down assembly with included hex key | |
|---|---|---|
| floor leveling | Manual rotation of felt-padded leg tips | |
| cross brace function | Rigidifies three splayed legs to prevent lateral wobble | |
| surface use suitability | Supports dining, laptop work, and display of tabletop items | |
| floor protection | Felt pads prevent scratches on hardwood, tile, and vinyl flooring | |
| space efficiency | Tripod leg design allows flexible chair placement around the full perimeter | |
| surface cleanability | Sealed lacquer finish allows wipe-clean with mild detergent | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| small apartment dining area | Fits compact 4person dining spaces without excessive footprint | |
|---|---|---|
| home office casual meeting nook | Serves as small conference table for informal 2-person discussions | |
| open-plan kitchen breakfast area | Provides casual dining surface adjacent to kitchen work zones | |
| breakout lounge seating area | Acts as elevated side table for drinks and reading materials | |
| studio apartment multi-use space | Functions as combined dining, work, and display surface for small units |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Applicable for safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Applicable for furniture assessment of surface resistance to cold liquids |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture for domestic dining use | |
|---|---|---|
| GB 18584-2001 | Applicable for limit of formaldehyde emission from interior wood furniture materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture for domestic dining use; 2. GB 18584-2001: Applicable for limit of formaldehyde emission from interior wood furniture materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
