Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1500 × 900 × 760 mm | |
|---|---|---|
| Overall dimension | 1500 x 900 x 760 mm | |
| Tabletop thickness | 30 mm | |
| Apron height | 80 mm | |
| Apron bottom clearance above floor | 650 mm | |
| Leg top section diameter | 50 mm | |
| Leg bottom section diameter | 30 mm | |
| Leg outward splay angle | 7 degrees | |
| Edge radius | 15 mm | |
| Knee clearance height | 650 mm | |
| Seating space per place setting | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load | 100 kg | |
|---|---|---|
| Single leg vertical static load | 80 kg | |
| Recommended seating capacity | 4 people | |
| Net product weight | 38 kg | |
| Finish scratch resistance cycle rating | 400 cycles | |
| Wood moisture content | 10% | |
| Connector shear strength | 120 kg per fitting | |
| Adjustable foot height adjustment | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | Solid hardwood (oak/walnut option) with matte oiled finish | |
|---|---|---|
| Support apron frame | Solid hardwood matching tabletop, mortise and tenon reinforced joinery | |
| Table legs | Solid hardwood tapered profile, outward angled for stability | |
| Edge treatment | Hand-sanded rounded bevel, no sharp corners | |
| Assembly hardware | Zinc-plated steel Allen bolt fittings with threaded wood inserts | |
| Foot pads | Non-marking nylon adjustable glides for uneven floors | |
| Finish coating | Low-VOC matte natural oil finish, 0.05mm dry film thickness | |
| Joint reinforcement | Wood dowel and glue reinforcement at apron-leg connections | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Two seats per long side, no end extension leaves, fixed 4-person layout | |
|---|---|---|
| Leg level adjustment | Rotating nylon glides adjust up to 10mm to compensate for uneven floor surfaces | |
| Surface use compatibility | Suitable for hot dinnerware up to 70C with placemat protection per standard oiled wood guidance | |
| Assembly requirement | Leg attachment to pre-fitted apron frame using included Allen key, no on-site joinery required | |
| Floor protection | Non-marking nylon foot pads prevent scuffing on hard flooring and low-pile carpet | |
| Cleaning requirement | Wipe with dry or slightly damp cloth, reapply wood oil annually to maintain finish | |
| Structural stability | Outward splayed legs reduce tipping risk when weight is applied to table edges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Fits compact 4-person dining nooks or open-plan living spaces with Scandinavian decor | |
|---|---|---|
| Small apartment eat-in kitchen | 1500mm length works in tight kitchen spaces without blocking walkways | |
| Home office meeting nook | Suitable for 4-person small team meetings or casual work sessions with 760mm work height | |
| Light commercial cafe seating | Durable solid wood construction works for low-traffic casual dining cafe spaces | |
| Open-plan lounge seating area | Natural wood finish complements neutral-toned soft seating in open lounge areas | |
| Studio apartment multi-use surface | Doubles as work desk and dining surface for small urban studio units |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength/durability/ stability, applicable for matching dining set use | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability test method, applicable for leg stability verification | |
| EN 71-3:2019 | Toy safety migration of elements, applicable if used in home dining areas with children present |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wood furniture, applicable for emissions testing | |
| GB/T 4893.4-2013 | Surface wear resistance test for furniture coatings, applicable for finish durability acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wood furniture, applicable for emissions testing; 3. GB/T 4893.4-2013: Surface wear resistance test for furniture coatings, applicable for finish durability acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
