Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 462 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Leg diameter at floor contact | 40 mm | |
| Drawer internal dimensions per unit | 530 x 380 x 80 mm | |
| Under-table floor clearance | 352 mm | |
| Tabletop corner radius | 120 mm | |
| Drawer front panel height | 80 mm | |
| Leg inset from table edge | 35 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load capacity | 68 kg | |
|---|---|---|
| Product net weight | 28 kg | |
| Recommended maximum place setting / decor load | 30 kg | |
| Finish abrasion resistance | 1000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | Solid natural hardwood, smooth matte clear lacquer finish 0.1mm thick | |
|---|---|---|
| Legs | Solid tapered hardwood, matching natural wood finish | |
| Drawer boxes | Solid wood frame with hardwood veneer panels | |
| Drawer slides | Full extension side-mounted metal slides, zinc plated | |
| Drawer handles | Integrated recessed wood pulls, no protruding metal hardware | |
| Apron frame | Solid hardwood, connected to legs with knockdown hardware | |
| Floor protection pads | Felt pads affixed to leg bases, 3mm thick | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Storage function | Two equal full-width pull-out drawers under the tabletop for concealed small item storage | |
|---|---|---|
| Assembly requirement | Knock-down leg attachment with 8 confirmat screws, fully detachable legs for transport | |
| Surface use function | Smooth sealed flat top for placing drinks, books, decorative items and snack trays | |
| Drawer operation | Smooth side-mount slide action with 90% extension, stop at full pull to prevent accidental removal | |
| Floor protection function | Felt leg pads prevent scratching hard tile, wood or stone flooring when repositioning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room sofa front placement | Positioned 400 mm in front of 3seater sofas for serving drinks and decor | |
|---|---|---|
| Small apartment lounge use | Compact footprint suitable for 25sqm living spaces without blocking walkways | |
| Casual lounge / reading area | Supports placement of books, beverages and small decor next to accent seating | |
| Natural wood interior schemes | Matches Scandinavian, Japanese, and light modern interior design palettes |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic seating tables | |
|---|---|---|
| EN 71-3:2019 | Safety of toys - Migration of certain elements, applicable if used in household spaces accessible to children |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and finish quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and finish quality checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
