Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1200 x 600 x 450 mm | |
|---|---|---|
| Tabletop thickness | 80 mm | |
| Tapered leg height | 150 mm | |
| Tapered leg top section diameter | 50 mm | |
| Front pull-out drawer internal dimensions | 520 x 480 x 120 mm | |
| Slatted-door storage compartment internal dimensions | 520 x 480 x 200 mm | |
| Vertical slat gap width on cabinet door | 12 mm | |
| Floor clearance under table apron | 120 mm | |
| Rounded corner radius | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load capacity | 100 kg | |
|---|---|---|
| Net product weight | 35 kg | |
| Recommended maximum number of users | 4 | |
| Finish water resistance rating | Level 2 for daily water stain resistance | |
| Structural warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | Solid rubberwood with natural matte water-based open-pore finish | |
|---|---|---|
| Table body frame and panels | Kiln-dried solid rubberwood with mortise-and-screw reinforced joints | |
| Tapered support legs | Solid rubberwood with angled splay design, pre-installed threaded mounting inserts | |
| Drawer front panel | Solid rubberwood with integrated semi-circular cutout pull handle | |
| Slatted cabinet door | Solid rubberwood vertical slats, framed construction with magnetic catch closure | |
| Drawer glides | Cold-rolled steel side-mounted 3/4 extension glides | |
| Interior storage shelf | 15mm thick solid rubberwood fixed panel | |
| Surface finish | Low-VOC matte water-based lacquer, 2 coat application | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Front pull-out drawer | 3/4 extension glide operation for storing small living room items like remotes and coasters | |
|---|---|---|
| Slatted door enclosed cabinet | Magnetic push-to-close door with vented slats for storing linens and media accessories | |
| KD leg assembly | Threaded leg mounting allows tool-free leg attachment for flat pack shipping | |
| Rounded corner safety design | Soft-edged table corners reduce impact injury risk in high-traffic living spaces | |
| Vented slat door design | Air circulation through slats prevents musty odors in enclosed stored soft goods | |
| Leveling adjustment | Plastic foot glides on leg bases adjust 5mm to compensate for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small apartment living room | 1.2m compact footprint fits in 25sqm living spaces in front of 3seater sofas | |
|---|---|---|
| Casual lounge area | Low 450mm height aligns with standard sofa seat height for convenient beverage and snack placement | |
| Rental property furnishing | Durable solid wood construction and simple assembly support cost-effective long-term rental staging | |
| Minimalist/Japandi interior schemes | Light natural wood finish and clean lines match Nordic and Japanese wabi-sabi design aesthetics | |
| Family media room use | Enclosed storage hides clutter while tabletop holds media devices, snacks and decorative items |
EU Market Access Requirements* EN Standards
| EN 12521:2015 Furniture - Strength, durability and safety for domestic tables | Applies to static load, impact and stability performance requirements for residential table products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to structural dimensional tolerance, finish adhesion and joint strength requirements for production inspection | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applies to formaldehyde and heavy metal emission limits for finished product acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to structural dimensional tolerance, finish adhesion and joint strength requirements for production inspection; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applies to formaldehyde and heavy metal emission limits for finished product acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
