Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 480 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Lower shelf dimensions | 800 x 400 mm | |
| Lower shelf height from floor | 200 mm | |
| Under-table clearance below top surface | 455 mm | |
| Metal frame tube cross-section | 40 x 20 mm | |
| Frame wall thickness | 1.5 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load | 68 kg | |
|---|---|---|
| Lower shelf static load | 30 kg | |
| Product net weight | 22 kg | |
| Finish abrasion resistance | Grade 2, 2000 cycles | |
| Floor contact static stability | Pass 10° tilt test | |
| Recommended service life | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame structure | Carbon steel rectangular tube with welded joints | |
|---|---|---|
| Frame finish | Matte black electrostatic powder coating | |
| Tabletop panel | High-density particleboard core with matte black melamine laminate | |
| Lower shelf panel | High-density particleboard core with matte black melamine laminate | |
| Floor contact pads | Non-marking polyethylene glides | |
| Hardware fasteners | Zinc-plated steel bolts and barrel nuts | |
| Panel edge banding | 1mm thick matte black PVC edge banding | |
| Weld finish | Ground smooth welds at frame joints | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Primary tabletop surface | Flat level surface for placing drinks, decor, and reading materials | |
|---|---|---|
| Lower offset shelf | Open auxiliary storage for magazines, remotes, or small decor items | |
| Floor stability adjustment | Fixed polyethylene glides with no height adjustment | |
| Assembly requirement | Knockdown assembly with included hex key and hardware | |
| Cleaning maintenance | Wipe clean with damp soft cloth, no harsh abrasives | |
| Mobility | Stationary design, no casters or lift mechanisms | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Placed in front of sofas for serving, decor, and everyday living room use | |
|---|---|---|
| Small apartment spaces | Open frame design creates lightweight visual presence for compact living areas | |
| Office lounge and waiting areas | Used in reception or break areas for guest refreshments and reading materials | |
| Modern minimalist interiors | Geometric open frame and monochrome finish suit contemporary, industrial, and Nordic design schemes | |
| Hard flooring surfaces | Non-marking glides prevent scuffs on wood, tile, and vinyl flooring |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Applies to safety, strength and durability requirements for domestic tables | |
|---|---|---|
| EN 1022:2019 | Applies to stability testing for domestic seating and tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden furniture for indoor use | |
|---|---|---|
| GB/T 1730-2007 | Applies to paint film hardness testing for metal furniture surfaces | |
| GB/T 4893.8-2013 | Applies to surface wear resistance testing for furniture panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden furniture for indoor use; 2. GB/T 1730-2007: Applies to paint film hardness testing for metal furniture surfaces; 3. GB/T 4893.8-2013: Applies to surface wear resistance testing for furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
