Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1000 x 760 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Floor to apron clearance | 670 mm | |
| Apron depth | 76 mm | |
| Leg cross-section | 50 x 50 mm square | |
| Leg inset from table corners | 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static tabletop load | 181 kg | |
|---|---|---|
| Unit net weight | 85 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Wood moisture content | 10% | |
| Frame joint static load | 136 kg per leg | |
| Warranty period | 3 years | |
| Seating capacity per side | 4 seats | |
| Total seating capacity | 8 seats | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | Solid hardwood core with light natural oak veneer | |
|---|---|---|
| Tabletop finish | Low-VOC scratch-resistant clear lacquer | |
| Legs | Solid square tapered oak wood legs | |
| Apron frame | Solid wood apron with notched leg joint detail | |
| Joinery hardware | Zinc-plated steel confirmat screws with wood dowel reinforcement | |
| Leg base pads | 10mm thick non-slip nylon floor protection pads | |
| Edge detail | 2mm eased mitered tabletop edge | |
| Finish coating thickness | 0.15mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Assembly requirement | Knock-down assembly with included hardware and illustrated instructions | |
|---|---|---|
| Floor adaptability | Optional adjustable nylon levelers on leg bases | |
| Under-table clearance | Open unobstructed clearance on all four sides | |
| Surface performance | Stain-resistant sealed surface suitable for food and beverage use | |
| Seating compatibility | Accommodates standard dining chairs with 480 mm seat height | |
| Structural rigidity | Reinforced apron frame prevents tabletop warping and wobble | |
| Color availability | Available in natural light oak, walnut, white, black finishes | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Office breakrooms | Provides 8-person seating for staff meals and informal collaboration | |
|---|---|---|
| Residential dining rooms | Seats 8 guests for family meals and casual dinner gatherings | |
| Casual cafe seating | Suitable for light commercial hospitality use with durable sealed finish | |
| Open co-working lounges | Creates shared communal dining and work surface for flexible spaces | |
| Staff pantries | Wipe-clean surface resists spills for daily high-frequency break area use |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Applicable for strength, durability and safety of domestic dining tables | |
|---|---|---|
| EN 71-3:2019 | Applicable for migration of certain elements for furniture used in public spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture | |
|---|---|---|
| GB 18584-2001 | Applicable for limit of formaldehyde emission in wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture; 2. GB 18584-2001: Applicable for limit of formaldehyde emission in wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
