Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1370 × 650 × 450 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Tabletop corner radius | 30 mm | |
| Leg cross-section | 80 x 80 mm | |
| Under-table floor clearance | 120 mm | |
| Edge overhang from leg face | 20 mm | |
| Apron height under tabletop | 60 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 26 kg | |
|---|---|---|
| Distributed tabletop static load | 50 kg | |
| Recommended place setting capacity | 4 place settings | |
| Finish scratch resistance rating | 2H pencil hardness | |
| Wood moisture content at delivery | 12% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop construction | Solid kiln-dried hardwood planks, edge-glued | |
|---|---|---|
| Table legs | Solid square-section hardwood, fixed corner mount | |
| Connecting apron | Solid hardwood apron, mitered corner joinery | |
| Surface finish | Clear non-toxic matte nitrocellulose lacquer | |
| Assembly hardware | Zinc-plated steel barrel bolts and wood screws | |
| Corner connection brackets | 2mm thick steel L-brackets with pre-drilled holes | |
| Foot pads | 8mm thick non-slip polyethylene pads on leg bases | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Surface function | Flat level surface for serving drinks, snacks and decor | |
|---|---|---|
| Assembly requirement | Knockdown assembly with included hardware, full tabletop pre-finished | |
| Floor protection | Non-marking foot pads prevent abrasion to tile and wood flooring | |
| Edge safety | Rounded tabletop corners eliminate sharp impact points | |
| Structural stability | Four corner leg configuration provides even weight distribution on flat floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room placement | Positioned in front of sofas for snack, drink and decor display | |
|---|---|---|
| Small apartment use | Compact footprint fits limited floor space in studio and small living areas | |
| Casual lounge spaces | Suitable for lounge areas and recreation rooms for light serving use | |
| Low-seating configuration | Works with floor cushions and low sofa seating for casual gathering setups |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic tables | |
|---|---|---|
| EN 71-3:2019+A1:2021 | Migration of certain elements, applicable if used in households with children |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural inspection | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural inspection; 2. GB 18584-2001: Limit of harmful substances in wood furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
