| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 1000 x 750 mm | |
|---|---|---|
| tabletop thickness | 45 mm | |
| leg cross-section | 50 x 50 mm | |
| end U-frame stretcher height | 100 mm | |
| central longitudinal stretcher height | 120 mm | |
| under-table knee clearance height | 705 mm | |
| lengthwise overhang per end | 150 mm | |
| widthwise overhang per side | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| distributed tabletop static load | 150 kg | |
|---|---|---|
| table net weight | 70 kg | |
| seating capacity | 8 persons | |
| finish abrasion resistance | 1000 cycles | |
| wood moisture content | 12% | |
| joint static shear load | 500 kg per connector | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop | Solid hardwood, walnut brown matte lacquer finish | |
|---|---|---|
| vertical legs | Solid hardwood, matching walnut stain, tapered profile | |
| end U-frame stretchers | Solid hardwood, floor-mounted support feet | |
| central longitudinal stretcher | Solid hardwood, cross-braced between end frames | |
| surface finish | Low-VOC matte nitrocellulose lacquer, 0.15mm dry film thickness | |
| assembly hardware | Zinc-plated steel bolts and barrel nuts, 8mm diameter | |
| floor contact pads | Non-marking felt pads, 5mm thickness | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| base support structure | Dual U-shaped end trestles connected by full-length central stretcher for lateral rigidity | |
|---|---|---|
| assembly type | Knock-down flat-pack assembly with included hardware and instructions | |
| seating access | Open under-table clearance to accommodate 3 chairs per long side and 1 per end | |
| floor protection | Felt pads on all base feet prevent scratches to hard flooring surfaces | |
| surface maintenance | Matte finish resists minor water rings, wipes clean with dry or damp soft cloth | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential dining room | Seats 8people for family meals and casual gatherings | |
|---|---|---|
| open-plan kitchen diner | Walnut brown finish complements modern and mid-century interior schemes | |
| small office break room | Provides durable seating for staff meal breaks and informal meetings | |
| restaurant private dining booth | Works for fixed premium dining seating with stable trestle base |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable for performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural tolerance checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture, applicable for formaldehyde emission verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural tolerance checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture, applicable for formaldehyde emission verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
