Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1300 x 650 x 460 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Corner radius | 50 mm | |
| Under-table clearance | 380 mm | |
| Apron height | 55 mm | |
| Leg top cross-section | 45 x 45 mm | |
| Leg splay angle | 12 degrees outward from vertical | |
| Foot contact pad diameter | 25 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static top load capacity | 80 kg | |
|---|---|---|
| Net product weight | 13 kg | |
| Vertical static load per leg | 30 kg | |
| Finish abrasion resistance | 400 cycles | |
| Wood moisture content at delivery | 10% | |
| Recommended maximum place setting weight | 30 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | MDF core with walnut wood veneer | |
|---|---|---|
| Table legs | Solid rubberwood with walnut-toned stain | |
| Curved apron | Solid hardwood construction matching leg material | |
| Surface finish | Matte clear lacquer coating, 0.1 mm thickness | |
| Floor protection pads | Felt material, 3 mm thickness | |
| Joinery hardware | Zinc-plated steel M6 dowel screws | |
| Veneer layer thickness | 0.6 mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Assembly requirement | Knock-down leg attachment with included hex key | |
|---|---|---|
| Floor protection | Adhesive felt pads prevent scratches on hard flooring | |
| Surface utility | Smooth sealed surface supports drink trays, books and decorative displays | |
| Structural stability | Splayed four-leg base resists tipping when load is applied to top edges | |
| Cleaning compatibility | Sealed finish supports wiping with dry or lightly damp cloth | |
| Placement compatibility | Designed for centered placement 450 mm in front of standard sofas | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living rooms | Placed in front of sofas for beverage, book and decorative item placement | |
|---|---|---|
| Apartment lounge spaces | Compact footprint fits small urban living areas without overcrowding | |
| Office break rooms | Provides casual surface for waiting area seating configurations | |
| Hotel guest room seating areas | Matches mid-century modern furnishing schemes for boutique hospitality | |
| Residential reception entryways | Functions as a low display surface near entry seating when space allows |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use, tables, safety strength and durability requirements | |
|---|---|---|
| EN 71-3:2019 | Migration of certain elements, applicable if used in households with small children |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for domestic indoor use | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, required for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for domestic indoor use; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, required for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
