| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 950 x 780 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Under-apron knee clearance | 660 mm | |
| Leg cross-section | 80 x 80 mm | |
| Apron height | 70 mm | |
| Long-side intermediate leg spacing | 900 mm | |
| End clearance between corner legs | 790 mm | |
| Floor glide height | 5 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load | 136 kg | |
|---|---|---|
| Seating capacity | 6 persons | |
| Net product weight | 78 kg | |
| Per-leg vertical static load rating | 45 kg | |
| Surface water resistance rating | Level 2, resistant to 24-hour cold water spills | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | Solid natural white oak planks, jointed for flat stability | |
|---|---|---|
| Tabletop finish | Clear matte UV-cured lacquer, 0.15mm dry film thickness | |
| Leg material | Solid square oak sections, matched grain to tabletop | |
| Apron frame | Solid oak hardwood, connected with reinforced hardware joints | |
| Floor glides | Non-marking high-density polyethylene pads | |
| Joint connectors | Zinc-plated steel confirmat screws with dowel alignment | |
| Wood moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Table structure | Fixed non-extendable rectangular top, no leaf storage or expansion mechanism | |
|---|---|---|
| Leg configuration | 6 total legs: 4 at corners, 1 midpoint per long side for structural rigidity | |
| Under-table access | Full open perimeter legroom with no central modesty panel or cross-bracing obstruction | |
| Floor adjustment | Fixed non-adjustable glides, designed for level hard floor surfaces | |
| Surface maintenance | Wipe-clean finish, resistant to common household food and beverage spills | |
| Assembly type | Knock-down flat-pack assembly, legs and aprons attach to tabletop with included hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Suitable for 6-person family meals and casual gatherings, standard dining height for chair compatibility | |
|---|---|---|
| Open-plan kitchen dining area | Light natural finish complements modern minimalist and Nordic interior schemes | |
| Small office breakout space | Durable solid wood surface suitable for casual meetings and employee meal areas | |
| Cafe or casual restaurant seating | Stable 6-leg structure supports frequent daily commercial use | |
| Studio apartment dining zone | Clean straight lines create visual lightness without excessive visual bulk |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable load and stability requirements | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface finishes, resistance to cold liquids and heat for dining surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structuralAcceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, formaldehyde emission ≤1.5mg/L |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structuralAcceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, formaldehyde emission ≤1.5mg/L; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
