Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 750 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 22 kg | |
|---|---|---|
| Tabletop static load capacity | 100 kg | |
| Recommended user capacity | 1 person | |
| Frame lateral stability load | 30 kg | |
| Surface abrasion resistance rating | 3000 cycles | |
| Warranty period for frame structure | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm high-density particleboard core | |
|---|---|---|
| Tabletop surface | Natural oak wood veneer | |
| Tabletop edge treatment | Matching solid wood edge banding | |
| Frame material | Q235 cold-rolled square steel tubing | |
| Frame finish | Matte black epoxy powder coating | |
| Leveling foot pads | Reinforced nylon with anti-slip rubber base | |
| Frame connection hardware | Zinc-plated steel bolts and locking nuts | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly method | Knock-down flat-pack assembly | |
|---|---|---|
| Leveling adjustment | 10mm vertical adjustment via threaded foot pads | |
| Cable routing space | 650mm wide open under-desk clearance | |
| Surface usage suitability | Supports monitor, laptop, keyboard and standard office supplies | |
| Footrest function | Lower horizontal frame rails act as fixed footrest | |
| Floor protection | Rubber foot pads prevent scratching hard floor surfaces | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workspace | Suitable for compact home study or remote work setups | |
|---|---|---|
| Open plan office workstation | Usable as single-seat workstations in flexible office layouts | |
| Small apartment dining surface | Functions as a compact dining table for 2 people in studio apartments | |
| Student study desk | Appropriate for secondary school or university student use | |
| Commercial co-working space | Deployable in co-working hot-desking zones |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 15372:2008 | Furniture durability and stability for non-domestic tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for metal furniture | |
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2017: Performance requirements for metal furniture; 3. GB 18584-2001: Limit of formaldehyde emission for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
