Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 450 mm | |
|---|---|---|
| Tabletop thickness | 45 mm | |
| Lower open shelf clearance above drawers | 180 mm | |
| Single front drawer internal dimensions | 520 x 320 x 120 mm | |
| Lower open shelf usable depth | 540 mm | |
| Square leg cross-section | 60 x 60 mm | |
| Apron frame height | 80 mm | |
| Corner radius | 3 mm | |
| Floor clearance under lower shelf | 100 mm | |
| Drawer front panel thickness | 18 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Recommended maximum user weight for edge seating | 100 kg | |
| Net product weight | 40 kg | |
| Available color options | 2 | |
| Edge banding thickness | 1 mm | |
| Recommended warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | Solid rubberwood/oak with clear matte eco-lacquer finish, sanded smooth | |
|---|---|---|
| Support legs | Solid square hardwood, fixed mortise and tenon joint to apron frame | |
| Lower open shelf panel | 18mm thick solid wood panel, fixed between leg assemblies | |
| Drawer fronts | Solid wood panels matching tabletop finish, flush fit to apron | |
| Drawer boxes | 12mm thick solid wood sides with plywood base, sanded interior | |
| Drawer slides | Cold-rolled steel side-mounted 3-section extension slides | |
| Back panel | 9mm thick plywood backing, fitted to rear frame | |
| Surface finish | Water-based low-VOC clear lacquer, 2-coat application with light polish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Smooth full-extension pull, 300mm travel, detent stop at fully open position | |
|---|---|---|
| Open shelf storage | Full-width accessible open storage for baskets, magazines and frequently used items | |
| Fixed height design | 450mm fixed working height, optimized for sofa-side use in living rooms | |
| Anti-tip stability | Four fixed wide-stance legs, 1 anti-tip wall anchor included for safety | |
| Surface protection | Stain-resistant lacquered surface, wipe-clean with soft damp cloth, no coaster required for cold drinks | |
| Hinge/drawer cycle rating | 50000 open/close cycles, meets residential furniture durability requirements | |
| Assembly requirement | Knock-down assembly with included hex key and instruction manual, 2-person assembly recommended | |
| Foot level adjustment | Fixed non-marring rubber foot pads, minor height adjustment via integrated felt glides | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Placed in front of sofas 450 mm seat height for tea service, reading and display | |
|---|---|---|
| Small apartment spaces | 1200mm compact footprint suitable for 25sqm living rooms, offers enclosed + open storage without blocking circulation | |
| Reception lounge areas | Used in office reception or casual meeting spaces for serving drinks and holding reading materials | |
| Nordic/Japandi style interiors | Natural light wood finish complements minimalist, warm neutral and natural material interior schemes | |
| Family use spaces | Rounded corners and stable fixed structure suitable for households with children and pets | |
| Low display use | Top surface suitable for decorative objects, table lamps and tea sets, lower shelf for woven storage baskets |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for domestic tables, applicable for structural performance testing | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for strength and durability of storage units, applicable for drawer and shelf load testing | |
| EN 71-3:2019 | Safety of toys - Migration of certain elements, applicable for lead/heavy metal limits if used in family spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, applicable for VOC and formaldehyde testing | |
| GB/T 4893.4-2013 | Test for surface wear resistance of furniture coatings, applicable for finish durability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture, applicable for VOC and formaldehyde testing; 3. GB/T 4893.4-2013: Test for surface wear resistance of furniture coatings, applicable for finish durability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
