Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 600 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 22 kg | |
| Seating capacity | 4 people | |
| Tabletop surface abrasion resistance | 400 cycles | |
| Structural service life | 10 years | |
| Leg vertical static load per leg | 50 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | Solid rubberwood planks, 25mm thick, natural matte clear lacquer finish | |
|---|---|---|
| Support apron | Solid rubberwood, 80mm height, glued and screwed to tabletop underside | |
| Four support legs | Solid rubberwood, tapered outward splayed design, natural finish | |
| Joinery hardware | Zinc-plated steel wood screws and corner brackets, 5mm diameter | |
| Surface finish | Water-based matte clear lacquer, 0.1mm coating thickness | |
| Edge treatment | Rounded 3mm radius edge profile on all tabletop edges | |
| Foot pads | Non-slip PE plastic foot pads, 2mm thickness, attached to leg bottoms | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed assembly structure | Permanent knockdown assembly, no extendable leaves or moving parts | |
|---|---|---|
| Floor protection | Replaceable plastic foot pads prevent floor scratches and allow minor level adjustment | |
| Surface cleanability | Smooth sealed lacquer surface allows wipe cleaning with damp cloth for food and drink spills | |
| Stability design | Outward splayed legs increase base footprint to 1100 x 500 mm to prevent tipping under uneven load | |
| Knockdown assembly | Legs detach from apron frame for flat-pack shipping and easy in-home assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 1260 x 660 x 120 mm | |
| Gross shipping weight | 25 kg | |
| Shipping volume (CBM) | 0.1 | |
| Assembly time | 30 minutes | |
| 20ft container loading quantity | 270 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining area | Suitable for small apartment dining nooks or kitchen dining spaces seating 4 people | |
|---|---|---|
| Casual kitchen use | Works as a breakfast or casual meal table with durable sealed wood surface for daily food contact | |
| Small home office | Can be used as a compact work desk for laptop and paperwork in open plan living spaces | |
| Matching furniture set | Pairs with light wood dining chairs of 450mm seat height for coordinated mid-century modern interior style | |
| Rental property furnishing | Durable solid wood construction suitable for long-term residential rental furnishing with low maintenance requirements |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
