Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 500 × 500 × 550 mm | |
|---|---|---|
| table top diameter | 500 mm | |
| table top thickness | 25 mm | |
| raised rim height | 10 mm | |
| base disc diameter | 300 mm | |
| pedestal stem diameter (narrowest point) | 60 mm | |
| under-table floor clearance | 495 mm | |
| base thickness | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| table top static load capacity | 25 kg | |
|---|---|---|
| net product weight | 8 kg | |
| surface abrasion resistance | 2000 cycles | |
| base tip-over resistance | 15 kg lateral force | |
| finish scratch resistance | Grade 2 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| table top substrate | 18 mm MDF engineered wood | |
|---|---|---|
| top surface finish | Matte black powder-coated laminate | |
| central pedestal stem | 1.5 mm thick steel tube | |
| base disc | 2 mm thick stamped steel plate | |
| surface coating | Polyester powder coat | |
| connecting hardware | Zinc-plated steel bolts | |
| base bottom pad | 3 mm thick non-slip EVA foam | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| raised rim containment | 10 mm raised lip around top edge | |
|---|---|---|
| freestanding installation | Tool-assisted assembly of three components | |
| 360-degree unobstructed access | Single central pedestal design | |
| floor protection | Non-slip EVA pads under base | |
| easy surface maintenance | Non-porous matte finish | |
| multi-zone placement compatibility | 300 mm diameter compact base | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| living room end table placement | Position beside sofas or armchairs for drinks, remotes and table lamps | |
|---|---|---|
| bedroom nightstand use | Compact footprint fits beside single or double beds for bedtime essentials | |
| small entryway accent table | Holds keys, decor and small items in narrow entry or hallway spaces | |
| lounge and waiting area use | Deploy in office breakout zones or reception areas for guest convenience | |
| apartment and small space furnishing | Slim pedestal design avoids leg obstruction in compact living spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic tables | |
|---|---|---|
| EN 15187:2006 | Furniture assessment of surface resistance to cold liquids for table top finishes |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to finished table quality inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to finished table quality inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
