Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3600 × 1200 × 750 mm | |
|---|---|---|
| Overall table dimensions | 3600 x 1200 x 750 mm | |
| Tabletop thickness | 80 mm | |
| Leg cross-section dimension | 100 x 100 mm | |
| Under-table knee clearance height | 670 mm | |
| Single matching bench dimensions | 1800 x 300 x 450 mm | |
| Bench seat slab thickness | 50 mm | |
| Horizontal stretcher height from floor | 120 mm | |
| Bench leg cross-section dimension | 80 x 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table total static distributed load capacity | 500 kg | |
|---|---|---|
| Wood moisture content at delivery | 12% | |
| Finish surface abrasion resistance | 1000 cycles | |
| Recommended commercial warranty period | 1 year | |
| Available finish color options | 3 | |
| Seating capacity | 12 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop slab | Solid pine or rubberwood with natural wood grain | |
|---|---|---|
| Table legs | Solid square-section hardwood with polished edges | |
| Connecting stretchers | Solid wood horizontal beams joined with mortise and tenon hardware | |
| Bench seat slabs | Solid wood matching tabletop material and finish | |
| Bench legs | Solid wood angled supports with lower connecting stretchers | |
| Surface finish | Clear water-based matte wood finish | |
| Floor contact pads | Anti-slip rubber pads fitted to all leg bases | |
| Joinery hardware | Zinc-plated steel bolt connectors for knockdown assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Dual-side bench seating to accommodate 12 meeting participants | |
|---|---|---|
| Assembly structure | Knock-down bolted assembly for on-site installation | |
| Under-table clearance | Open unobstructed leg space across full table length | |
| Tabletop surface function | Flat smooth surface supports laptops, documents, and meeting materials | |
| Stability structure | Double trestle leg frames with lower stretchers prevent lateral wobble | |
| Floor protection | Integrated rubber pads prevent floor scratches and reduce movement noise | |
| Customization option | Custom length and width configurations available for room layout fit | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate meeting rooms | Suitable for medium team meetings for 12participants | |
|---|---|---|
| Open office collaboration areas | Functions as a shared worktable for group project work | |
| Training and seminar spaces | Supports training sessions with bench seating for flexible attendee arrangement | |
| Small startup office spaces | Natural wood finish suits casual modern office design aesthetics | |
| Shared community workspaces | Durable solid wood construction withstands frequent daily use in public areas |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Furniture strength, durability, and stability for tables |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard for load, stability, and durability | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and ergonomics |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood tables | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances in wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood tables; 2. GB 18584-2001: Indoor decoration material limit of harmful substances in wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
