Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 480 mm | |
|---|---|---|
| Overall set footprint (nested) | 800 x 800 x 480 mm | |
| Larger table diameter | 800 mm | |
| Smaller table diameter | 700 mm | |
| Table height (both units) | 480 mm | |
| Tray lip height | 20 mm | |
| Tabletop thickness | 18 mm | |
| Leg length | 462 mm | |
| Leg diameter (top attachment point) | 35 mm | |
| Leg splay angle from vertical | 15 degrees | |
| Floor clearance under tabletop | 440 mm | |
| Nesting insertion depth | 620 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static load per tabletop | 25 kg | |
|---|---|---|
| Set total net weight | 16 kg | |
| Static stability load per leg | 20 kg | |
| Tray lip containment height | 20 mm | |
| Surface abrasion resistance | Class 2 | |
| Recommended weight capacity for placed items | 20 kg per table | |
| Floor protection rating | Non-marking | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Large tabletop | 18mm MDF substrate with white matte paint finish | |
|---|---|---|
| Small tabletop | 18mm MDF substrate with white matte paint finish | |
| Tray perimeter lip | Integral MDF with matching white painted finish | |
| Table legs | Solid natural oak, tapered cylindrical profile, clear matte lacquer | |
| Leg attachment hardware | Zinc-plated steel screw-in inserts, pre-installed in tabletop base | |
| Foot pads | Non-slip non-marking injection-molded plastic, fitted to leg bottoms | |
| Surface coating thickness | 0.15 mm | |
| Leg finish | Water-based clear lacquer, 2 coats | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting storage function | Small table slides 620mm under larger table to reduce footprint | |
|---|---|---|
| Tray edge containment | 20mm raised lip secures remotes, mugs and decor from sliding off | |
| Quick knock-down assembly | Legs screw into pre-installed inserts without additional tools | |
| Floor protection | Plastic foot pads eliminate hard wood contact with flooring | |
| Flexible use configuration | Tables can be separated for use as side surfaces or nested for compact use | |
| Stable three-leg design | Splayed legs create triangular support to eliminate wobble on uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room front-of-sofa placement | For holding drinks, decor and remote controls in residential seating areas | |
|---|---|---|
| Small apartment space-saving use | Nesting design reduces footprint when full surface area is not needed | |
| Flexible extra surface use | Separated small table functions as side table for seating or accent surface | |
| Mid-century modern / Scandinavian interiors | Natural oak legs and white tray top match Nordic and retro design schemes | |
| Light commercial lounge use | Suitable for boutique waiting areas or co-working lounge seating zones |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Residential furniture safety for tables | EN 12521:2015 | |
|---|---|---|
| Surface scratch resistance | EN 15186:2012 | |
| Formaldehyde emission from wood panels | EN 312:2010 P2 grade |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 18580E1 grade | |
|---|---|---|
| Furniture structural strength | GB/T 10357.1 | |
| Surface coating heavy metal content | GB 18584 |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 18580E1 grade; 2. Furniture structural strength: GB/T 10357.1; 3. Surface coating heavy metal content: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
