Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 750 mm | |
|---|---|---|
| Tabletop diameter | 800 mm | |
| Tabletop thickness | 18 mm | |
| Under-table knee clearance height | 730 mm | |
| Leg splay diameter at floor | 720 mm | |
| Individual leg diameter at top joint | 38 mm | |
| Individual leg diameter at floor contact | 25 mm | |
| Foot glide diameter | 20 mm | |
| Mounting bracket height at leg joint | 60 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 113 kg | |
|---|---|---|
| Recommended seating capacity | 4 people | |
| Product net weight | 18 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Leveling adjustment range per foot | 5 mm | |
| Recommended warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | E1 grade medium density fiberboard | |
|---|---|---|
| Tabletop finish | White high-gloss baked paint finish | |
| Leg material | Solid natural beech wood | |
| Leg-to-top mounting brackets | Powder-coated white steel | |
| Foot glides | Chrome-plated steel base with non-marking rubber pad | |
| Assembly hardware | Zinc-plated steel screws | |
| Edge finish | Smooth rounded machined edge | |
| Leg wood finish | Clear matte lacquer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly type | Knock-down screw attachment of legs to tabletop | |
|---|---|---|
| Floor protection | Non-marking rubber glides prevent scratches on hard flooring | |
| Stability design | Tripod three-leg layout eliminates wobble on flat hard floors | |
| Surface maintenance | Wipe-clean non-porous top resists common dining spills | |
| Seating access | Unobstructed open under-top space allows full perimeter seating | |
| Minor leveling | Adjustable rubber feet compensate for slight floor unevenness | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small residential dining nook | Fits 4diners in compact apartments or studio kitchens | |
|---|---|---|
| Breakfast area in open-plan homes | Scandinavian style pairs with light wood or white dining chairs | |
| Casual meeting space in small offices | Compact size works for 3person informal discussions | |
| Rental property furnishing | Durable easy-clean surface and simple assembly suit turnover use | |
| Cafe or small bistro seating | Stable tripod design supports daily commercial light use | |
| Studio home work surface | Suitable height for laptop use paired with standard desk chairs |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Test methods for furniture table strength and stability verification |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for table structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MDF tabletop substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for table structural safety; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MDF tabletop substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
