Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 900 × 1800 × 750 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Leg cross-section | 80 x 80 mm square | |
| Floor to apron clearance | 700 mm | |
| Leg height | 710 mm | |
| Tabletop corner radius | 30 mm | |
| Apron height | 120 mm | |
| Per-seat width allocation | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static distributed tabletop load | 150 kg | |
|---|---|---|
| Static vertical load per leg | 75 kg | |
| Seating capacity | 6 persons | |
| Net product weight | 45 kg | |
| Surface horizontal impact resistance | 14 J | |
| Wood moisture content | 12% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | Solid rubberwood edge-glued planks, natural matte clear finish | |
|---|---|---|
| Legs | Solid square-section rubberwood, matching natural finish | |
| Apron frame | Solid rubberwood horizontal support frame, dowel and bolt connected | |
| Surface finish | Clear water-based polyurethane matte coating, 0.15 mm dry film thickness | |
| Joint hardware | Zinc-plated steel 8 mm bolt connectors and wood dowels | |
| Foot pads | 4 mm thick non-slip PE pads at each leg base | |
| Connector reinforcement | Steel corner brackets at apron-leg joints, 2 mm thick | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structure type | Fixed non-extendable rectangular dining table | |
|---|---|---|
| Assembly method | Knockdown assembly, legs attach to apron frame with included hardware | |
| Floor protection | Included non-slip foot pads prevent hardwood and tile floor scratches | |
| Clearance design | Unobstructed under-table space with no center crossbar | |
| Edge treatment | Rounded eased edge profile on all tabletop perimeters | |
| Leveling adjustment | 5 mm height adjustment range via adjustable foot pads | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Primary use for family daily meals, seats 6 people comfortably | |
|---|---|---|
| Small open-plan kitchen | Fits compact apartment dining areas without obstructive crossbars | |
| Rental and furnished apartments | Durable solid wood construction suits high-turnover residential use | |
| Casual home office space | Doubles as a large work surface for home projects or group work | |
| Small event and break room use | Suitable for light commercial office break rooms seating 6staff |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable for procurement testing | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - seating and tables, stability test method applicable |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to residential dining table acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to residential dining table acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
