Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static tabletop load capacity | 150 kg | |
|---|---|---|
| Recommended seating capacity | 6 people | |
| Net product weight | 48 kg | |
| Frame joint static load rating | 100 kg per leg | |
| Surface abrasion resistance | 10000 rub cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | Natural oak veneer or solid pine with clear matte lacquer finish | |
|---|---|---|
| Leg frame | 1.5mm thick square steel tube with matte black powder coating | |
| Longitudinal cross support | 40x40mm square steel welded to leg units for torsional stability | |
| Tabletop edge | Straight square edge with lightly sanded rounded corner treatment | |
| Frame to tabletop fasteners | M8 steel carriage bolts with pre-installed threaded inserts in tabletop underside | |
| Floor contact pads | 3mm thick non-slip PE pads at each leg base | |
| Surface coating on wood | Low-VOC clear nitrocellulose lacquer, 3 coat application | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Assembly requirement | Knock-down assembly, attaches two leg sets to tabletop with included hardware | |
|---|---|---|
| Floor protection | Non-marring pads prevent scratching hard flooring surfaces without additional glides | |
| Seating accessibility | Open trestle design allows 2 seats on each long side and 1 seat on each short end | |
| Stability reinforcement | Welded cross support reduces frame wobble on uneven floors up to 3mm variation | |
| Surface maintenance | Smooth sealed finish allows wipe cleaning with mild household cleaners without water damage | |
| Weight distribution | Trestle leg layout distributes load evenly across 4 floor contact points | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Serves 6 people for daily family meals and casual gatherings, fits standard dining spaces | |
|---|---|---|
| Open plan kitchen dining area | Minimal industrial style coordinates with modern, rustic or loft kitchen designs | |
| Small office break room | Provides stable work and dining surface for employee meal breaks and casual meetings | |
| Cafe or bistro seating | Durable easy-clean surface works for high-traffic casual food service environments |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture, strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating and tables stability test method |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop structural strength | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable if engineered wood substrate is used | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop structural strength; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable if engineered wood substrate is used; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
