Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| Tabletop slab thickness | 45 mm | |
| Leg panel wall thickness | 50 mm | |
| Embedded tea tray zone dimensions | 800 x 400 mm | |
| Sintered stone inlay width | 350 mm | |
| Leg circular cutout diameter | 180 mm | |
| Chair seat height | 450 mm | |
| Chair overall dimensions | 550 x 500 x 820 mm | |
| Under-table knee clearance height | 680 mm | |
| Clearance between two support legs | 1200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Table static distributed load capacity | 150 kg | |
|---|---|---|
| Recommended maximum seating capacity | 6 users | |
| Sintered stone surface heat resistance | 180 °C | |
| Set total net weight | 185 kg | |
| Wood frame moisture content | 12% | |
| Finish abrasion resistance cycles | 2000 cycles | |
| Integrated electric boiler load rating | 1500 W | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table frame and legs | Walnut-toned solid hardwood, matte clear lacquer finish | |
|---|---|---|
| Tabletop center inlay | Polished light gray sintered stone, 12mm thickness | |
| Integrated tea tray | Polished black natural Wujin stone, slotted drainage design | |
| Chair frames | Matching solid hardwood, mortise and tenon joinery | |
| Chair seat panels | Solid wood veneered engineered wood panel, clear lacquer finish | |
| Table edge trim | Solid wood edge banding, rounded corner profile | |
| Structural connectors | Zinc-plated steel hardware, hex head bolts | |
| Protective foot pads | Non-slip 5mm thick rubber pads, floor-protecting design | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea service zone | Recessed fixed black stone tray with dedicated space for boiler, teaware and drainage | |
|---|---|---|
| Built-in electric boiling station | Embedded induction cooker compatible with standard glass teapots for water heating | |
| Concealed wastewater routing | Hidden drainage channel connecting tea tray to under-table removable wastewater bucket | |
| Four-sided seating access | Open under-table space with no central obstruction to accommodate seating on all sides | |
| Decorative leg cutouts | Circular open cutouts on both end box legs for aesthetic and weight reduction | |
| Scratch-resistant work surface | Sintered stone inlay resists scratches and heat from daily tea preparation use | |
| Stackable chair storage | Chairs designed to tuck fully under the table when not in use to save space | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Home tea room | Suitable for dedicated home tea spaces for daily kung fu tea practice and small family gatherings | |
|---|---|---|
| Office reception area | Appropriate for executive office reception zones to host visiting clients for tea service | |
| Commercial tea house | Durable enough for light commercial use in private tea house booths and lounge areas | |
| Living room accent set | Functions as a multi-purpose dining and tea table in open-plan new Chinese style living rooms | |
| Recommended matching accessories | Pairs with ceramic tea sets, small potted plants, and fabric floor rugs to complete the zen interior aesthetic |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable to structural performance | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable to included armchairs | |
| EN 16139:2013 | Furniture - Strength, durability and safety for non-domestic seating, applicable for public reception use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood table and chair frames | |
|---|---|---|
| GB/T 4893.1-2021 | Surface wear resistance test method for furniture finishes, applicable to lacquered wood surfaces | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission control | |
| GB/T 35607-2017 | Green product assessment standard for furniture, applicable for environmentally friendly material selection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood table and chair frames; 2. GB/T 4893.1-2021: Surface wear resistance test method for furniture finishes, applicable to lacquered wood surfaces; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission control; 4. GB/T 35607-2017: Green product assessment standard for furniture, applicable for environmentally friendly material selection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
