Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1100 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Central knee clearance width | 700 mm | |
| Seated knee clearance height | 620 mm | |
| Left pedestal width | 550 mm | |
| Right pedestal width | 550 mm | |
| Central modesty panel height | 480 mm | |
| Plinth base height | 100 mm | |
| Recessed foot cutout depth | 40 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Net product weight | 160 kg | |
| Recommended user count | 1 person | |
| Warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1-grade high-density fiberboard with walnut wood veneer | |
|---|---|---|
| Desktop finish | Matte polyurethane lacquer coating | |
| Pedestal cabinet frames | Solid wood edge framing with veneered panel infills | |
| Plinth base | Solid hardwood construction | |
| Drawer slides | Cold-rolled steel full-extension slides | |
| Cabinet hinges | Soft-close steel concealed hinges | |
| Cable management grommets | ABS plastic with brushed metal trim | |
| Joinery hardware | Zinc-plated steel three-in-one connectors | |
| Edge trim | Solid wood edge banding matching walnut finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Left pedestal storage | 1 utility drawer + 1 legal/letter file drawer | |
|---|---|---|
| Right pedestal storage | 2 utility drawers + 1 enclosed cabinet compartment | |
| Center knee bay access | Open seated leg room with fixed modesty panel | |
| Cable management | 2 desktop grommets + under-desk cable tray | |
| Drawer operation | Full-extension soft-close drawer action | |
| Cabinet door operation | Soft-close 110-degree opening doors | |
| Plinth foot clearance | Recessed base cutouts for seated foot placement | |
| Assembly configuration | Knock-down assembly with cam-lock connectors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suited for CEO, general manager, or director private workspace | |
|---|---|---|
| Boardroom ancillary workspace | Pairs with traditional wood conference room furniture for cohesive design | |
| Government/enterprise office | Fits formal institutional office environments with classic wood furniture standards | |
| High-end home office | Works for dedicated premium home executive workspaces with classic decor | |
| Seated work configuration | Optimized for use with high-back executive office chairs at standard work height | |
| Desktop device support | Supports laptop, dual monitors, desk phone, and standard office accessories | |
| Document storage use | Integrated pedestal storage holds files, office supplies, and personal work items |
EU Market Access Requirements* EN Standards
| Office desk safety standard | EN 527:2011 | |
|---|---|---|
| Surface finish durability | EN 12720:2013 | |
| Hardware durability standard | EN 15338:2007 |
US and Canada office-furniture standards
| Desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Storage component standard | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Desk dimension standard | GB/T 3326 | |
|---|---|---|
| Surface durability standard | GB/T 4893.8 | |
| Material formaldehyde limit | GB 18580 |
This product must meet the following technical requirements: 1. Desk dimension standard: GB/T 3326; 2. Surface durability standard: GB/T 4893.8; 3. Material formaldehyde limit: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
