Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2200 x 1000 x 760 mm | |
|---|---|---|
| desktop thickness | 50 mm | |
| edge band thickness | 2 mm | |
| central knee clearance width | 800 mm | |
| under-desk knee clearance height | 735 mm | |
| left pedestal dimensions | 600 x 1000 x 620 mm | |
| right pedestal dimensions | 600 x 1000 x 620 mm | |
| central drawer width | 1000 mm | |
| pedestal foot height | 70 mm | |
| drawer front panel thickness | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 150 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| product net weight | 115 kg | |
| surface finish hardness | 3H | |
| structure warranty period | 5 years | |
| maximum seated user weight | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop core | Solid walnut wood or walnut veneer over E0-grade plywood | |
|---|---|---|
| desktop finish | Matte PU clear sealer with multi-step sanding | |
| drawer boxes | 12mm thick Baltic birch plywood | |
| drawer slides | Cold-rolled steel three-section soft-close slides | |
| pedestal frame | Solid wood frame with mortise and tenon joinery | |
| decorative inlay | Carved solid wood circular grille accent | |
| base feet | Solid wood stepped block feet with protective floor glides | |
| drawer hardware | Antique bronze finished metal drawer pulls | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| pedestal storage | 2 pedestals each with 2 drawers for office supplies and file storage | |
|---|---|---|
| central drawer | 1 shallow central front drawer for stationery and small office items | |
| drawer operation | Full-extension soft-close slides with 450mm travel for full drawer access | |
| locking mechanism | Central lock securing all 5 drawers for document security | |
| cable management | 2 x 60mm diameter desktop cable grommets with under-desk cable tray | |
| surface use | Rounded bullnose edge profile to reduce wrist strain during long work sessions | |
| floor protection | Non-marking glides on all feet to prevent hard floor scratching | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| private executive office | Suitable for director/CEO private offices, formal professional aesthetic | |
|---|---|---|
| boardroom ancillary space | Can be used as a speaker or document prep desk in formal meeting rooms | |
| high-end home office | Appropriate for luxury residential home offices with traditional decor style | |
| government/ institutional office | Suitable for formal government or state-owned enterprise executive spaces | |
| reception manager office | Ideal for reception area manager workstations needing formal storage capacity | |
| matching office set | Pairs with matching leather executive chair and wall bookcase for coordinated workspace |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, for dimensional compliance | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Safety requirements | |
| EN 13722:2004 | Furniture - Strength and durability of office storage units, for pedestal performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural qualityAcceptance inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable if engineered wood substrate is used |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural qualityAcceptance inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable if engineered wood substrate is used; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
