| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 1770 x 760 x 790 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Central knee clearance width | 720 mm | |
| Central knee clearance height | 620 mm | |
| Central knee clearance depth | 600 mm | |
| Pedestal drawer front height | 160 mm | |
| Edge band thickness | 2 mm | |
| Support foot height | 80 mm | |
| Modesty panel height | 400 mm | |
| Cable grommet diameter | 80 mm | |
| Rounded corner radius | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Single drawer slide load rating | 25 kg | |
| File drawer load rating | 45 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Net weight (desk unit) | 132 kg | |
| Recommended maximum user weight | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | High-density fiberboard (HDF) substrate | |
|---|---|---|
| Desktop surface | Walnut wood veneer with matte polyurethane topcoat | |
| Edge trim | Solid hardwood matching walnut finish | |
| Pedestal cabinet panels | Medium-density fiberboard (MDF) with walnut veneer | |
| Drawer slides | Cold-rolled steel ball bearing slides | |
| Support feet | Solid hardwood tapered feet | |
| Modesty panel | Engineered wood with decorative recessed groove detail | |
| Cable grommets | ABS plastic with walnut finish cap | |
| Internal drawer boxes | Laminated engineered wood with dovetail joinery | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Drawer storage configuration | 4 utility drawers plus 2 locking file drawers | |
|---|---|---|
| Drawer soft-close mechanism | Soft-close glides with 45 mm extension | |
| Cable management system | Dual recessed desktop grommets with under-desk cable tray | |
| File drawer locking function | Central locking bar secures both file drawers | |
| Fixed height working surface | Fixed 790 mm working height | |
| Modesty panel privacy function | Solid front panel blocks under-desk visibility | |
| Floor leveler adjustment | Integrated adjustable feet glides | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for CEO, senior manager, or executive personal workspace | |
|---|---|---|
| Middle manager office space | Suitable for 15sqm individual office rooms | |
| Boardroom ancillary workspace | Usable as meeting room side desk for document and presentation material storage | |
| High-end home office | Appropriate for dedicated home executive offices for remote senior professionals | |
| Reception back office workspace | Usable in reception back areas for administrative management use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions | |
|---|---|---|
| EN 527-2:2002 | Office work tables - Part 2: Mechanical safety requirements | |
| EN 14073-2:2004 | Office furniture - Storage furniture - Part 2: Safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for performance and safety | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Tests for performance and safety |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 4897.3-2017 | Particleboard for furniture use | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 4897.3-2017: Particleboard for furniture use; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
