Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 900 x 760 mm | |
|---|---|---|
| Tabletop thickness | 80 mm | |
| Walnut wood veneer thickness | 0.6 mm | |
| Solid wood edge banding thickness | 8 mm | |
| Central knee clearance width | 800 mm | |
| Central knee clearance height | 580 mm | |
| Left drawer pedestal dimensions | 500 x 650 x 680 mm | |
| Right cabinet pedestal dimensions | 500 x 650 x 680 mm | |
| Drawer internal height (per unit) | 150 mm | |
| Right cabinet internal shelf clearance | 320 mm | |
| Plinth base height | 60 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop even static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge cycle rating | 80000 cycles | |
| Product net weight range | 160 kg | |
| Recommended user weight capacity | 130 kg | |
| Paint surface hardness | 2H | |
| Wood moisture content | 12% | |
| Product warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | E0-grade engineered fiberboard | |
|---|---|---|
| Work surface finish | 0.6mm walnut wood veneer | |
| Edge treatment | 8mm thick solid walnut edge banding | |
| Pedestal frame | Solid hardwood frame | |
| Drawer/door panels | Walnut veneer engineered wood panels | |
| Drawer slides | 3-section steel soft-close ball-bearing slides | |
| Cabinet hinges | Hydraulic soft-close steel hinges | |
| Pull handles | Brass-finish metal hardware | |
| Coating finish | Matte polyurethane paint | |
| Plinth base | Solid wood structural support | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Left pedestal storage | Three vertically stacked drawers for office supply and document storage | |
|---|---|---|
| Right pedestal storage | Single enclosed cabinet with adjustable shelf for large item storage | |
| Drawer operation | Soft-close full-extension slides with automatic silent retraction | |
| Cabinet door operation | Soft-close hydraulic hinge with 110-degree opening angle | |
| Cable management | 60mm dual desk-top grommets with under-desk cable tray | |
| Cable tray load capacity | 5 kg | |
| Assembly configuration | Knock-down flat pack with cam-lock and screw hardware | |
| Customization option | Available in alternative sizes and wood tone finishes | |
| Surface resistance | Heat, stain and scratch resistant coating for daily office use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 25sqm private offices for senior management or director use | |
|---|---|---|
| Home office workspace | Suitable for premium home office setups requiring formal storage | |
| Meeting room leader station | Functions as a head table for small 6person conference rooms | |
| Government and institutional office | Matches formal professional aesthetic for public sector workspaces | |
| Recommended pairing | Matches with solid wood armchairs with upholstered seats for coordinated style | |
| Maximum office layout fit | Works with back wall storage credenzas and visitor seating in front | |
| Surface equipment compatibility | Supports dual monitors, desk lamp, and standard office document placement |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable standard for safety and dimensional requirements of office work desks | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Applicable standard for mechanical safety and stability requirements for office desks | |
| EN 12720:2009+A1:2013 | Applicable standard for cold liquid stain resistance of furniture surfaces | |
| EN 312:2010 | Applicable standard for performance requirements of wood-based particleboard panels |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden office furniture | |
|---|---|---|
| GB/T 3327-2016 | Applicable standard for dimensions and performance of office desks | |
| GB 18584-2001 | Applicable standard for formaldehyde emission limits of wooden interior furniture | |
| GB/T 4893.4-2013 | Applicable standard for surface wear resistance testing of furniture coatings |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden office furniture; 2. GB/T 3327-2016: Applicable standard for dimensions and performance of office desks; 3. GB 18584-2001: Applicable standard for formaldehyde emission limits of wooden interior furniture; 4. GB/T 4893.4-2013: Applicable standard for surface wear resistance testing of furniture coatings; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
